>>>>>型號:CX11000001 電源裝置和 I/O 接口
【功能描述】
Beckhoff CX11000001該電源具有重要功能：集成的 NOVRAM 允許對過程數據進行防電壓故障存儲，LC 顯示屏具有兩行，每行 16 個字符，用于輸出系統和用戶消息。連接總線端子模塊和現場總線盒模塊的可能性使控制器具有高度可變、可擴展的 I/O 電平，具有各種信號。I/O 數據存儲在 DPRAM 中，CPU 可通過系統總線訪問該 DPRAM。所有其他系統組件的電源通過內部 PC/104 總線確保;不需要單獨的供應管線。CX 系統的電源可現場更換。電源提供了重要的功能:集成的NOVRAM允許過程數據的防電壓故障存儲，具有兩行各16個字符的LC顯示器用于系統和用戶信息的輸出。連接總線終端和現場總線盒模塊的可能性產生了具有高度可變的、可擴展的控制器輸入-輸出與各種各樣的信號電平。I/O數據存儲在DPRAM中，CPU可以通過系統總線訪問它。所有其他系統組件的電源通過內部PC/104總線保證;不需要單獨的供給線。CX系統的電源可現場更換。除了電源，CX1100-0001還提供了三個基本功能:顯示器、導航開關和NOVRAM。它不包含I/O連接器。
電源模塊有多種輸入輸出選擇，并且可以重復加或交叉加，構成積木式組合電源，從而實現多路輸入輸出。相比分立式，調試更加簡單安全，使設計應用大大簡化，縮短開發時間。模塊一般采用自動化工藝，保證品質和可靠性。電源模塊是經過了專業電源研發團隊按照嚴格標準來選擇元件，經過設計和開發，進行過完善的可靠性測試和批量生產測試。而分立式方案就較難進行深入的測試。模塊一般采用了多層PCB回鋁基板，功率密度較高，體積較小，節省了系統的占用空間。目前DC-DC模塊的1/4磚高達1000W，分立式方案難以達到這樣的標準。
>>>>>型號:CX11000001 電源裝置和 I/O 接口
【英文介紹】
Beckhoff CX11000001 The power supply has important features: the integrated NOVRAM allows for voltage fail-proof storage of process data, and the LC display has two lines of 16 characters each for output system and user messages. The possibility of connecting the bus terminal module and the field bus box module gives the controller a highly variable, scalable I/O level with a variety of signals. I/O data is stored in DPRAM, which is accessible by the CPU through the system bus. Power to all other system components is secured via the internal PC/104 bus; No separate supply lines are required. The power supply of the CX system can be replaced on-site. The power supply provides important features: integrated NOVRAM allows voltage fail-proof storage of process data, LC display with two lines of 16 characters each for the output of system and user information. The possibility of connecting bus terminals and field bus box modules produces a controller with highly variable and scalable input-output with a wide variety of signal levels. The I/O data is stored in DPRAM and the CPU can access it via the system bus. Power to all other system components is guaranteed via the internal PC/104 bus; No separate supply lines are required. The power supply of the CX system can be replaced on-site. In addition to power, the CX1100-0001 offers three basic functions: display, navigation switch, and NOVRAM. It does not include an I/O connector.
The power module has a variety of input and output options, and can be repeated or cross-added to form a modular power supply, so as to achieve multiple input and output. Compared with separate, debugging is more simple and safe, which greatly simplifies the design and application and shortens the development time. Modules generally use automated processes to ensure quality and reliability. The power module has been selected by a professional power supply research and development team in accordance with strict standards, and has been designed and developed, and has carried out perfect reliability testing and mass production testing. Discrete schemes are more difficult to conduct in-depth testing. Modules generally use multi-layer PCB aluminum substrate, high power density, small volume, saving the system space. At present, the 1/4 brick of the DC-DC module is as high as 1000W, and the separate scheme is difficult to reach such a standard.
