AO810V2 3BSE038415R1  | 模擬輸出 | CI853 3BSE018103R1 |  TU830V1 3BSE013234R1

　　基本信息

　　型號：AO810V2 3BSE038415R1

　　類型：模擬輸出

　　信號規格：0..20毫安，4..20毫安

　　通道數： 8

　　AO810/AO810V2 模擬輸出模塊具有 8 個單極性模擬輸出通道。為了監控與D/A轉換器的通信，串行數據被回讀和驗證。在回讀期間接收開路診斷。該模塊循環執行自診斷。模塊診斷包括過程電源監控，當輸出電路的電源電壓較低時，會報告該監控。該錯誤報告為通道錯誤。信道診斷包括信道的故障檢測(僅在活動信道上報告)。如果輸出電流小于輸出設定值且輸出設定值大于 1 mA，則報告錯誤。

　　特點和優勢

　　8 通道 0...20 mA，4...20 mA 輸出

　　OSP 在檢測到錯誤時將輸出設置為預定狀態

　　模擬輸出短路固定至ZP或+24 V

　　Basic information

　　Model: AO810V2 3BSE038415R1

　　Type: Analog output

　　Signal specification: 0... 20 mah, 4... 20 ma

　　Number of channels: 8

　　The AO810/AO810V2 analog output module has 8 unipolar analog output channels. To monitor communication with the D/A converter, serial data is read back and verified. Receive open circuit diagnostics during read back. The module performs a self-diagnosis loop. Module diagnostics include process power monitoring, which is reported when the power supply voltage of the output circuit is low. The error is reported as a channel error. Channel diagnostics includes fault detection of the channel (reported only on the active channel). If the output current is less than the output set value and the output set value is greater than 1 mA, an error is reported.

　　Characteristics and advantages

　　8 channel 0... 20 mA, 4... 20 mA output

　　The OSP sets the output to a scheduled state when an error is detected

　　Analog output shorted fixed to ZP or +24 V
