>>>>>型號:5SHX1445H0002 驅動板模塊 直流調速中壓板
【功能描述】
ABB 5SHX1445H0002 3BHL000387P0101直流調速中壓板
IGBT系列高頻驅動板，主要采用SG3525A作為PWM脈沖形成，輸出脈沖頻率范圍20KHZ—60KHZ,脈沖間隔互為180度，死區時間可以自行調整。可適用于IGBT全橋逆變串聯諧振感應加熱裝置調頻調功。功率范圍：10KW—120KW,該控制板接線少，控制集中，沒有調試，工作電源電壓為三路交流雙18V/1A及四個22V/0.5A的電源。具有過流，過壓，卻水，多種狀態指示，并提供開關型霍爾保護接口和線性霍爾保護接口，有全橋逆變IGBT驅動電路，此板可直接組裝IGBT高頻感應加熱裝置。
IGCT是將GTO芯片與反并聯二極管和門極驅動電路集成在一起，再與其門極驅動器在外圍以低電感方式連接，結合了晶體管的穩定關斷能力和晶閘管低通態損耗的優點，
在導通階段發揮晶閘管的性能，關斷階段呈現晶體管的特性。IGCT 具有電流大、阻斷電壓高、開關頻率高、可靠性高、結構緊湊、低導通損耗等特點，而且造成本低，成品率高，有很好的應用前景。
己用于電力系統電網裝置（100MVA）和的中功率工業驅動裝置（5MW)IGCT在中壓變頻器領域內成功的應用了11年的時間（到09年為止)，由于IGCT的高速開關能力無需緩沖電路，因而所需的功率元件數目更少，
運行的可靠性大大增高。IGCT集 IGBT（絕緣門極雙極性晶體管）的高速開關特性和GTO（門極關斷品閘管）的高阻斷電壓和低導通損耗特性于一體，一般觸發信號通過光纖傳輸到IGCT單元。
在ACS6000的有緣整流單元的相模塊里，每相模塊由IGCT 和二極管、鉗位電容組成，由獨立的門極供電單元GUSP為其提供能源。
>>>>>型號:5SHX1445H0002 驅動板模塊 直流調速中壓板
【英文介紹】
ABB 5SHX1445H0002 3BHL000387P0101 DC speed regulating medium pressure board
IGBT series high frequency driver board mainly adopts SG3525A as PWM pulse formation, the output pulse frequency range is 20Khz-60khz, the pulse interval is 180 degrees each other, the dead time can be adjusted. It can be applied to frequency and power regulation of IGBT full-bridge inverter series resonant induction heating device. Power range: 10kwe-120kW, the control board less wiring, centralized control, no debugging, the working power supply voltage for three AC double 18V/1A and four 22V/0.5A power supply. With over current, over voltage, but water, a variety of state indicators, and to provide switching type Hall protection interface and linear hall protection interface, a full bridge inverter IGBT drive circuit, this board can be directly assembled IGBT high frequency induction heating device.
IGCT integrates the GTO chip with the anti-parallel diode and gate driver circuit, and then connects it with the gate driver in a low inductance mode at the periphery, combining the stable turn-off ability of the transistor and the advantages of the low on-state loss of the thyristor.
The performance of thyristor is displayed in the on-stage, and the characteristics of transistor are displayed in the off-stage. IGCT has the characteristics of large current, high blocking voltage, high switching frequency, high reliability, compact structure, low on-off loss and so on, and has a good application prospect.
IGCT has been used in power system power grid devices (100MVA) and medium power industrial drive devices (5MW)IGCT has been successfully applied in the field of medium voltage inverter for 11 years (until 2009), because the high-speed switching capability of IGCT does not need buffer circuits, so the number of power components required is less.
The reliability of operation is greatly increased. The IGCT combines the high-speed switching characteristics of the IGBT (insulated gate bipolar transistor) with the high blocking voltage and low on-loss characteristics of the GTO (gate shutdown gate tube), and the trigger signal is generally transmitted to the IGCT unit through the optical fiber.
In the phase module of the ACS6000 marginal rectifier unit, each phase module consists of an IGCT, a diode, and a clamp capacitor, and is powered by an independent gate power supply unit GUSP.
