>>>>>型號:216DB61 控制卡模塊 運動控制需求
【功能描述】
216DB61 控制卡模塊通常是采用專業的運動控制芯片或高速DSP來滿足一系列運動控制需求的控制單元，其可通過PCI、PC等總線接口安裝到PC和工業PC上，可與步進和伺服驅動器連接，驅動步進和伺服電機完成各種運動(單軸運動、多軸聯動、多軸插補等)，接收各種輸入信號(限位原點信號，sensor)，可輸出控制繼電器、電磁閥、氣缸等元件。用戶可使用VC、VB等開發工具，調用運動控制卡函數庫，快速開發出軟件。
216DB61 控制卡模塊以一個通用的XYZ三軸通用控制平臺開發為例，此平臺加上膠槍、刀具等模塊后可用于點膠、切割等用途，運動控制卡采用深圳眾為興數控開發的ADTA，ADTA運動控制卡是一款經濟實用型運動控制卡，軸伺服/步進電機控制，最大脈沖輸出頻率為MHz，每軸均有位置反饋輸入；可實現-軸直線插補，可實現XYZ三軸插補，進行整體配合動作；帶有路隔離數字輸入，路隔離數字輸出，可控制膠槍、刀具等模塊；具有外部信號驅動、硬件緩存等功能，能滿足絕大部分的軸以下工作平臺的運動控制需求。
>>>>>型號:216DB61 控制卡模塊 運動控制需求
【英文介紹】
216DB61 control card module is usually a professional motion control chip or high-speed DSP to meet a series of motion control needs of the control unit, which can be installed on PC and industrial PC through PCI, PC and other bus interfaces, and can be connected with stepper and servo drivers. Drive the stepper and servo motor to complete various movements (single-axis movement, multi-axis linkage, multi-axis interpolation, etc.), receive various input signals (limit origin signal, sensor), and output control relays, solenoid valves, cylinders and other components. Users can use VC, VB and other development tools, call the motion control card function library, quickly develop the software.
216DB61 control card module to a general XYZ three-axis general control platform development as an example, this platform with glue gun, tool and other modules can be used for dispensing, cutting and other purposes, the motion control card using Shenzhen Zhongweixing CNC development of ADTA, ADTA motion control card is an economic and practical type of motion control card, shaft servo/stepper motor control, The maximum pulse output frequency is MHz, and each axis has position feedback input; Can realize linear interpolation of -axis, can realize XYZ three-axis interpolation, and carry out the overall coordination action; With road isolation digital input, road isolation digital output, can control the glue gun, tool and other modules; It has the functions of external signal drive, hardware cache, etc., which can meet the motion control needs of most of the sub-axis working platforms.
>>>>>型號:216DB61 控制卡模塊 運動控制需求
