>>>>>型號:288055-01 瞬態數據接口模塊 框架接口模塊

【功能描述】

3500/22M框架接口模塊是連接3500框架的基本接口。它支持本特利內華達公司專有協議，用作組態框架和收集機器信息。RIM必須安裝在框架的槽位(與電源模塊緊挨著)。

RIM提供一個連接，它支持當前本特利內華達通訊處理器(外部瞬態數據接口TDIX和外部動態數據接口DDIX)。

RIM使用兩種類型的I/O模塊，即框架接口I/O模塊和數據管理I/O模塊。這些I/O模塊讓你把主計算機和通訊處理器與3500框架連接起來，一次只能在RIM(盤裝或架裝框架中)的后面或RIM(壁掛式框架)的上面安裝一個框架接口I/O模塊。

對于3500監測系統，有效的兩種框架接口I/O模塊是RS-232/RS-422I/O 模塊和調制解調器I/O模塊。以下特性為兩種I/O模塊共有的。

框架接口I/O模塊必須安裝在框架接口模塊的后面(盤裝或架裝框架)或者在框架接口模塊的上面(壁掛式框架)。

 >>>>>型號:288055-01 瞬態數據接口模塊 框架接口模塊

【英文介紹】

The 3500/22M frame interface module is the basic interface to connect to the 3500 frame. It supports Bentley Nevada proprietary protocols and is used as a configuration framework and to collect machine information. The RIM must be installed in a slot in the frame (next to the PSU).

RIM provides a connection that supports current Bentley Nevada communications processors (External Transient Data Interface TDIX and External Dynamic Data Interface DDIX).

RIM uses two types of I/O modules, the Framework Interface I/O module and the data management I/O module. These I/O modules allow you to connect the main computer and communication processor to the 3500 frame, and only one frame interface I/O module can be installed at a time behind the RIM(disk or rack frame) or on top of the RIM(wall-mounted frame).

For 3500 monitoring systems, the two effective frame interface I/O modules are the RS-232/RS-422I/O module and the modem I/O module. The following features are common to both types of I/O modules.

The frame interface I/O module must be mounted behind the frame interface module (disk or rack mounted frame) or on top of the frame interface module (wall mounted frame).
