>>>型號:3500/93 顯示接口模塊 用于工業自動化和控制系統

【功能描述】

3500/93 顯示接口 I/O 模塊是一款顯示接口模塊，其制造符合美國石油學會標準670。它主要用于系統顯示，并提供存儲在機架中的所有3500機械保護系統信息的本地或遠程視覺指示。這些信息包括所有通道、

監視器、繼電器模塊、鍵相模塊或轉速計模塊的數據，它們都被列在系統事件列表中。

3500/93顯示接口I/O模塊的特點是，每個3500機架最多可支持兩臺顯示器，每臺顯示器需要一個空閑插槽來插入與其對應的DIM。DIM和顯示器之間的電纜連接，當顯示器不是正面安裝時，可以從3500機架

的正面或機架背面的I/O模塊完成。

該模塊還提供了連續、在線監測功能，適用于機械保護應用，并為早期識別機械故障提供重要的信息。其工作流程包括從現場取得的傳感器輸入信號提供給3500監測器框架內的監測器和鍵相位通道，數據被采

集后，與報警點比較并從監測器框架送到一個或多個地方處理。

在3500系統中，3500/93顯示接口I/O模塊起著關鍵的作用，它使得用戶可以方便地訪問和查看機械保護系統的各種信息，從而實現對機械設備的有效監控和維護。

>>>>型號:3500/93 顯示接口模塊 用于工業自動化和控制系統

【英文介紹】

The 3500/93 Display Interface I/O module is a display interface module manufactured in accordance with API Standard 670. It is primarily used for system display and provides a local or remote

visual indication of all 3500 mechanical protection system information stored in the rack. This information includes data for all channels, monitors, relay modules, key phase modules, or tachometer

 modules, which are listed in the System Event list.

The 3500/93 display interface I/O module features support for up to two monitors per 3500 rack, each of which requires a free slot to insert its corresponding DIM. The cable connection between

the DIM and the display, when the display is not front-mounted, can be done from the front of the 3500 rack or the I/O module on the back of the rack.

The module also provides continuous, in-line monitoring capabilities for mechanical protection applications and provides important information for early identification of mechanical failures. The

 workflow consists of sensor input signals taken from the field being fed to the monitor and key phase channels within the 3500 monitor frame, the data being collected, compared with the alarm

point and sent from the monitor frame to one or more places for processing.

In the 3500 system, the 3500/93 display interface I/O module plays a key role, which enables users to easily access and view various information of the mechanical protection system, so as to achieve

effective monitoring and maintenance of mechanical equipment.
