SLS1508  RRS3202   |T8110B型|冗余邏輯求解器|

硬件:

冗余邏輯求解器(SLS 1508)和終止塊

SISNet中繼器(參見單獨的產品數據表)

載波擴展電纜

冗余sls1508邏輯求解器。

本地對等總線擴展電纜

右1寬載波終端

邏輯求解器(SLS 1508)包含邏輯求解功能

并提供一個接口到16個I/O通道，可以

配置為離散輸入，

離散輸出，模擬輸入

(HART)和HART兩態輸出通道。邏輯解決者

終端塊安裝在8寬的載體上。

邏輯求解器之間通過

運營商通過雙通道，本地對等總線(SISnet)和遠程

同行的戒指。本地邏輯求解器由相同的delta托管

控制器和遠程邏輯求解器由不同的

均控制器。邏輯求解器由24v直流電源供電

電源與驅動電動機的電源是分開的

DeltaV控制器和I/O。邏輯解算器以奇數安裝

插槽(1,3,5,7)上的8寬載體。冗余邏輯求解器

使用四個插槽

Hardware:

Redundant logic solver (SLS 1508) and termination block

SISNet Repeater (see separate product data sheet)

Carrier extension cable

Redundant sls1508 logic solver.

Local peer bus extension cable

Right 1 wide carrier terminal

The logic solver (SLS 1508) contains the logic solver function

And provide an interface to 16 I/O channels, yes

Configured for discrete input, discrete output, analog input

(HART) and HART two state output channels. Logical solver

The terminal block is mounted on an 8-wide carrier.

Logic solvers pass between them

Operators operate through dual channels, local peer-to-peer bus (SISnet) and remote

A companion ring. The local logic solver is hosted by the same delta

Controllers and remote logic solvers are different

Equalizing controller. The logic solver is powered by a 24v DC supply

The power supply is separate from the power supply that drives the motor

DeltaV controller and I/O. Logical solvers are installed in odd numbers

Slots (1,3,5,7) on the 8-wide carrier. Redundant logic solver

Use four slots
