FCM100ET  |  通信模塊  |   實現無縫通信

　　型號：FCM100ET

　　電源電壓:24VDC

　　功耗:<20 瓦特

　　通信協議:Modbus、Profibus、

　　EthernetlP

　　數據傳輸速率:高達 10 Mbps

　　額定溫度范圍:-40°C至 +70°C

　　防護等級:IP67

　　FCM100ET 通信模塊

　　FCM100ET是一款在工業自動化和控制系統中常用的通信模塊。具體來說，它能夠?qū)崿F(xiàn)100Mbps以太網到2Mbps現場總線的轉換，使得系統能夠高效地在不

　　同網絡之間傳輸數據。此外，該模塊的波特率是軟件可選擇的，可以與所有I同一波特率的FBM的通道相匹配，實現無縫通信。

　　在一個4800波特率的設置下，F(xiàn)CM100ET每個模塊都能提供雙向數字通信發射機與系統之間的連接，適用于現場總線。而在600波特率的設置下，該模塊不僅提供雙向數字通信，還允許0到20mA模擬信號用于其他設備，如緊急停機系統。

　　此外，F(xiàn)CM100ET誦信樟塊在每條消息接收時能夠處理5條每秒4800波特率的數據，或在600波特率下每1.5秒處理一條消息，這些消息包含兩個測量變量

　　(即主變量，如壓力和變送器溫度)、32位浮點安全信息和診斷信息以及消息檢查等，這些信息可用于所有元素系統。

　　FCM100ET也是一個基于Windows的應用程序工是程序編程，它可以在沒有驅動器的情況下使用并連接到驅動器，監控屏墓上用戶實時選擇，并在傳輸文件

　　時，自動選擇適當?shù)某绦蚪缑妗?/p>

　　總的來說，F(xiàn)CM100ET通信模塊以基高效的通信能力、廣泛的應用范圍和靈活的配置選項，為工業自動化和控制系統提供了穩定可靠的通信解決方案

　　Model: FCM100ET

　　Power supply voltage :24VDC

　　Power consumption :<20 watts

　　Communication protocol :Modbus, Profibus,

　　EthernetlP

　　Data transfer rate: up to 10 Mbps

　　Rated temperature range :-40°C to +70°C

　　Protection level :IP67

　　FCM100ET communication module

　　FCM100ET is a communication module commonly used in industrial automation and control systems. Specifically, it is able to achieve the conversion of 100Mbps Ethernet to 2Mbps fieldbus, so that the system can be efficient in no

　　Transfer data to and from the network. In addition, the baud rate of the module is software-selectable and can be matched with the channels of all FBMS with the same baud rate to achieve seamless communication.

　　At a 4800 baud rate setting, each module of the FCM100ET provides a connection between the bidirectional digital communication transmitter and the system, suitable for fieldbuses. At 600 baud, the module not only provides two-way digital communication, but also allows analog signals from 0 to 20mA to be used in other devices, such as emergency shutdown systems.

　　In addition, the FCM100ET is capable of processing five pieces of data at 4,800 baud rates per second at each message received, or one message every 1.5 seconds at 600 baud rates, which contain two measurement variables

　　(i.e., principal variables such as pressure and transmitter temperature), 32-bit floating point safety and diagnostic information, and message checks, which are available for all element systems.

　　FCM100ET is also a Windows-based application that is programmed to be used without a drive and connected to the drive, monitor the screen on the grave of the user's real-time selection, and transfer files

　　When, automatically select the appropriate program interface.

　　In general, the FCM100ET communication module provides a stable and reliable communication solution for industrial automation and control systems based on efficient communication capabilities, a wide range of applications and flexible configuration options
