>>>>>型號:IC695CPE310  RX3i CPE310 控制器 32k字模擬量I/O

【功能描述】

部件號IC695CPE310

外形背板

用戶內存13MB

I/O32k位離散量I/O，32k字模擬量I/O

能量包隨附

冗余支持介質冗余(MRP)，帶PNC001

以太網端口3-2端口開關10/100/1000

以太網協議SRTP客戶端/服務器，Modbus TCP/IP，OPC UA，EGD，PROFINET，DNP3電站，IEC-61850客戶端，IEC-104服務器，HART Passthrough

串行協議ASCII串行協議，Modbus/RTU

遠程I/O設備255單工，帶PNC001

USB接口1個USB-A 2.0

環境0至60℃

機構認證UKCA，UL，cUL，RoHS，CCC，F(xiàn)CC，Reach，UL HazLoc C1D2，ATEX Zone 2

海事認證ABS，BV，LRDNV GL

>>>>>型號:IC695CPE310  RX3i CPE310 控制器 32k字模擬量I/O

【英文介紹】

Part number IC695CPE310

Contour backplane

User memory 13MB

I/O32k bit discrete I/O, 32k word analog I/O

Energy packs are included

Redundancy Supports media redundancy (MRP) with PNC001

Ethernet port 3-2 Port switch 10/100/1000

Ethernet Protocol SRTP client/server, Modbus TCP/IP, OPC UA, EGD, PROFINET, DNP3 power Station, IEC-61850 client, IEC-104 server, HART Passthrough

Serial Protocol ASCII Serial protocol, Modbus/RTU

Remote I/O device 255 simplex with PNC001

USB port One USB-A 2.0

Environment 0 to 60℃

Agency certification UKCA, UL, cUL, RoHS, CCC, FCC, Reach, UL HazLoc C1D2, ATEX Zone 2

Maritime Certification ABS, BV, LRDNV GL

>>>>>型號:IC695CPE310  RX3i CPE310 控制器 32k字模擬量I/O
