>>>>>型號:IS215UCVEH2AE 控制系統組件  直角引腳連接器

【功能描述】

該IS215UCVEH2AE是通用電氣 Mark VI Speedtronic 控制系統的一個組件。該板用作VME控制卡。VME卡架是Mark VI的標準機架，可作為13槽或21槽機架使用。

IS215UCVEH2AE是一個帶有前面板的矩形板。面板的頂部和底部都有一個固定螺釘，用于在將電路板安裝到機架系統后幫助將電路板固定到位。前面板包括一個以太網端口、兩個 COM 端口和一個 LAN 端口。它還有一個夾層卡的開口。

電路板本身包括電路板主體內的垂直引腳連接器和沿電路板邊緣的直角引腳連接器。此外，該板還具有多個集成電路、電阻器、電容器、扼流圈和其他組件。此外，在電路板的中心有一個以一定角度安裝的小電路板，散熱器蓋位于電路板的一半以上。

 >>>>>型號:IS215UCVEH2AE 控制系統組件  直角引腳連接器

【英文介紹】

The IS215UCVEH2AE is a component of the General Electric Mark VI Speedtronic control system. The board is used as a VME control card. The VME bracket is the standard Mark VI bracket and can be used as a 13 - or 21-slot rack.

IS215UCVEH2AE is a rectangular board with a front panel. Both the top and bottom of the panel have a set screw to help hold the board in place after mounting it into the rack system. The front panel includes one Ethernet port, two COM ports, and one LAN port. It also has an opening for a sandwich card.

The board itself consists of a vertical pin connector within the board body and a right Angle pin connector along the edge of the board. In addition, the board has multiple integrated circuits, resistors, capacitors, chokes, and other components. In addition, there is a small circuit board mounted at an Angle in the center of the circuit board, and the radiator cap is located more than half of the circuit board.
