IC697PWR724 | 電源模塊 | 可以與單個機架應用一起運行
GEIC697PWR724電源模塊參數如下:
制造商:GE。
零件號:IC697PWR724
重量:2.46磅)
標稱額定電壓:24伏直流電。
輸入電壓范圍:18~32伏直流電:
輸入功率:160瓦
輸入浪涌能量:大于22焦耳。
輸出功率:大于90瓦。
輸出電壓:+5伏、+12伏和-12伏直流電。
穿越時間:10毫秒。
VME:兼容。
溫度范圍:0~60攝氏度。
過電壓限制:5伏直流電
IC697PWR724模塊是由GE Fanuc Automation設計、制造和分銷的電源模塊。該電源模塊可在 24 伏直流電壓和 90 瓦輸出功率下運行。該模塊的設計使其能夠插入機架，特別是在其最左側的插槽上。該模塊通過機架上的 48 針背板安裝連接器連接。該電源模塊提供不同的電壓，以根據操作和邏輯電平排序信號進行調整。GE Fanuc Automation IC697PWR724電源模塊可以與單個機架應用一起運行，并且可以同時為 2 個機架供電。總負載必須在規格額定值內，并且通過電纜與第二個機架進行互連。
IC693APU300 GE 高速計數器
IC693CBL301 GE 總線擴展電纜
IC695CHS016 GE 接線板
IC694PWR330 GE 擴展電源模塊
IC695PSA040 GE 控制器
IC697CGR935 GE 處理器
IC698CHS017 GE 可編程邏輯控制器
IS200ECTBG1ADE GE 渦輪控制模塊
IS215UCVHM06A-IS200PMCIH1ACC-- GE 數字信號發生器模塊
The parameters of the GEIC697PWR724 power module are as follows:
Manufacturer :GE.
Part number :IC697PWR724.
Weight :2.46 pounds)
Nominal rated voltage :24 volts DC.
Input voltage range :18~32 volts DC:
Input power :160 watts
Input surge energy: greater than 22 joules.
Output power: greater than 90 watts.
Output voltage :+5 volts, +12 volts and -12 volts DC.
Travel time :10 milliseconds.
VME: compatible.
Temperature range :0~60 degrees Celsius.
Overvoltage limit :5 volts DC
The IC697PWR724 module is a power module designed, manufactured and distributed by GE Fanuc Automation. The power module can operate at 24 volts DC and 90 watts of output power. The module is designed so that it can be inserted into the rack, especially on its leftmost slot. The module is connected via a 48-pin backplane mounting connector on the rack. The power supply module provides different voltages to adjust according to the operation and logic level sequencing signal. The GE Fanuc Automation IC697PWR724 power module can operate with a single rack application and can power 2 racks at the same time. The total load must be within the specification rating and connected to the second rack by cable.
