IC698PSA100 | 電源模塊 | 配有螺絲型輸入端子
品牌：GE
型號：IC698PSA100
產品名稱：CPU處理器模塊
產品凈寬：53毫米
產品凈高：125毫米
產品凈深/長度：260毫米
產品凈重：0.7公斤
IC698PSA100是 PACSystem RX7i 電源模塊，由艾默生自動化制造，以前隸屬于 GE 智能平臺 (GE IP)。此電源模塊安裝在任何 RX7i 標準機架的最左側插槽，特別是插槽 0。它配有螺絲型輸入端子，設計用于輸入電壓范圍 85 至 264 VAC(標稱電壓為 120 / 240 VAC)，頻率為 47 至 63 Hz 和 100-150VDC(標稱電壓為 125 VDC)。外部電源連接必須使用 AWG #16 (1.3 mm2) 實心或絞合銅線進行，絕緣額定值為 75°C (167°F)。對于接地連接，請使用絕緣額定值為 75°C (167°F) 的 #12 (3.3 mm2) 銅線。適當端接 GND 連接可以顯著消除系統噪音(如果不是)。
IC698PSA100 提供的最大輸出功率為 100 瓦，這是所有三 (3) 個輸出端子的總輸出功率，可提供 4.875 至 5.25 伏、0—20 安培、5.1 VDC，標稱值;11.64 至 12.6 伏，0—2 安培，+12 VDC，標稱值和 –12.60 至 –11.64 伏，0—1 安培，-12 VDC，標稱值。該電源模塊的穿越時間最短為 15 ms，保持時間最短為 5 ms。它還具有主動過壓和過流限制，特別是 +5VDC 時的 5.7 至 6.7 V 過壓保護;+5 VDC 輸出時為 21A;+12 VDC 輸出時為 2.5A，-12 VDC 輸出時為 3.5A。
該電源模塊的工作溫度為 0°C 至 60°C(32°F 至 140°F)，隔離額定值為 1500 VDC。
Brand: GE
Model: IC698PSA100
Product name: CPU processor module
Product width: 53 mm
Product height: 125 mm
Product net depth/length: 260 mm
Net weight: 0.7 kg
The IC698PSA100 is a PACSystem RX7i power module manufactured by Emerson Automation and formerly owned by GE Intelligence Platform (GE IP). This power module is installed in the leftmost slot of any RX7i standard rack, especially slot 0. It is equipped with screw input terminals and is designed for input voltage range 85 to 264 VAC (nominal voltage 120/240 VAC), frequency 47 to 63 Hz and 100 to 150VDC (nominal voltage 125 VDC). External power connections must be made using AWG #16 (1.3 mm2) solid or stranded copper wire with an insulation rating of 75°C (167°F). For ground connections, use #12 (3.3 mm2) copper wire with an insulation rating of 75°C (167°F). Properly terminated GND connections can significantly eliminate system noise (if not).
The IC698PSA100 provides a maximum output power of 100 watts, which is the total output power of all three (3) output terminals, providing 4.875 to 5.25 volts, 0-20 amps, 5.1 VDC, nominal values; 11.64 to 12.6 volts, 0-2 amps, +12 VDC, nominal values and -12.60 to -11.64 volts, 0-1 amps, -12 VDC, nominal values. The power module has a minimum traverse time of 15 ms and a minimum hold time of 5 ms. It also has active overvoltage and overcurrent limits, especially 5.7 to 6.7 V overvoltage protection at +5VDC; +5 VDC output is 21A; The output value is 2.5A for +12 VDC and 3.5A for -12 VDC.
The power module operates from 0°C to 60°C (32°F to 140°F) and has an isolation rating of 1500 VDC.
