IC697BEM731 | 天才總線控制器模塊 | 90-70可編程邏輯控制器
型號:IC697BEM731
Ald分辨率12bit
采樣率5mhz, 2mhz, 1mhz, 500khz....
500赫茲
存儲深度(每通道)512k樣點/ch
觸發方式 手動觸發、內觸發、外觸發
工作方式 在線、離線(黑匣子)
信號輸入v/q或v/icp
通訊接口rj45以太網接口
IC697BEM731是一款天才總線控制器模塊，是GE Fanuc系列90-70可編程邏輯控制器(PLC)家族的一部分。該模塊主要用于連接多達三十(30)個設備，并通過在同一總線上的所有配置設備之間傳遞令牌來傳輸數據。
IC697BEM731具有一個(1)通道用于與駐留在同一總線上的設備接口，一個(1)手持監視器(HHM)端口用于使用MS DOS或Windows編程軟件配置器功能將配置下載到模塊。
在交付IC697BEM731時，它沒有提供定義的總線地址。組態軟件默認設置的標準地址為153.6 Kbaud，總線地址為31。這個默認地址可以通過下載一個有效的配置到CPU來修改。配置153.6 k波特(標準)時，通信總線最大允許距離為2000ft;當配置為153.6 k波特(擴展)時，3500英尺;76.8 k波特時為4500英尺，38.4 k波特時為7500英尺。必須將位于同一總線或網絡上的所有設備配置為相同的波特率，否則將無法建立通信或可能出現通信不穩定。
Model :IC697BEM731
Ald resolution 12bit
Sampling rate 5mhz, 2mhz, 1mhz, 500khz....
500 Hertz
Storage depth (per channel)512k sample point /ch
Trigger Mode Manual trigger, internal trigger, and external trigger
Working mode Online, Offline (Black box)
Signal input v/q or v/icp
Communication port rj45 Ethernet port
The IC697BEM731 is a Genius Bus controller module that is part of the GE Fanuc series 90-70 Programmable Logic controller (PLC) family. This module is primarily used to connect up to thirty (30) devices and transfer data by passing tokens between all configured devices on the same bus.
The IC697BEM731 has a (1) channel for interfacing with devices residing on the same bus, and a (1) Handheld Monitor (HHM) port for downloading the configuration to the module using the MS DOS or Windows programming software Configurator feature.
When the IC697BEM731 was delivered, it did not provide a defined bus address. By default, the standard address set by the configuration software is 153.6 Kbaud and the bus address is 31. This default address can be modified by downloading a valid configuration to the CPU. When configured with 153.6k baud (standard), the maximum allowable distance of the communication bus is 2000ft; 3500 feet when configured at 153.6k baud (extended); 4,500 feet at 76.8 k baud and 7,500 feet at 38.4 k baud. All devices located on the same bus or network must be configured to the same baud rate, otherwise communication will not be established or may be unstable.
