IC697CPU772RR  |   90-70 系列 | 可編程邏輯控制器

該IC697CPX772是艾默生自動化 90-70 系列可編程邏輯控制器 (PLC) 系列中的中央處理器 (CPU) 模塊。該模塊專門帶有多個通信接口，一 (1) 個 RJ11 串行通信接口和兩 (2) 個 9 針 D 殼 RS485 通信端口。該處理器支持 SNP 從站、無斷 SNP(從站)、SNPX 和 RTU 串行協議。

　　該處理器具有內置 512 KB 隨機存取存儲器 (RAM) 和 256 KB 非易失性閃存。該處理器支持浮點計算，浮點計算是實際計算和事務中使用的數據格式，因?yàn)楦↑c(diǎn)數學支持十進制值。它可以容納高達 2K 的離散輸入和任意組合的離散輸出以及 8K 字的模擬輸入和輸出數據。

　　該處理器配備 80486DX4 微處理器，時鐘速度為 96 MHz。對于 Bollean 執行，每個布爾指令的執行速度為 0.4 微秒。它還配備了一個電池供電的實時時鐘 (RTC)，精度為每天 +/- 3.5 秒，最大和經過的時間時鐘精度為 +/- 0.1%。該模塊的鋰電池的目錄號為 IC697ACC701，在 5 度溫度下運行時保質期為 20 年，內存保留期為 6 個月。該IC697CPX772的電流消耗為 3.1 A，工作溫度為 0-60 攝氏度。

IC200ALG262J  差分電流模塊

IC200ALG322 模塊  驅動換能器

IC200MDL240B  離散輸入模塊

IC200MDL240B  分布式輸入/輸出

IC200MDL930  IC200MDL240B 輸出模塊

IC220PBI002  IC200ALG262J 網絡接口單元

IC609TCU1100B 可編程邏輯控制器

　　The IC697CPX772 is a central processing unit (CPU) module in Emerson Automation's 90-70 series Programmable Logic Controller (PLC) family. The module is specially equipped with multiple communication interfaces, one (1) RJ11 serial communication interface and two (2) 9-pin D-shell RS485 communication ports. The processor supports SNP slave, interruptionless SNP (slave), SNPX, and RTU serial protocols.

　　The processor has 512 KB of built-in random access memory (RAM) and 256 KB of non-volatile flash memory. The processor supports floating-point computation, which is the data format used in actual calculations and transactions, because floating-point mathematics supports decimal values. It can accommodate up to 2K discrete inputs and any combination of discrete outputs as well as 8K words of analog input and output data.

　　The processor is equipped with an 80486DX4 microprocessor with a clock speed of 96 MHz. For Bollean execution, each Boolean instruction is executed at 0.4 microseconds. It also comes with a battery-powered real-time clock (RTC) with an accuracy of +/- 3.5 seconds per day and a maximum and elapsed time clock accuracy of +/- 0.1%. The module's lithium battery, catalog number IC697ACC701, has a shelf life of 20 years when operating at 5 degrees and a memory retention period of 6 months. The IC697CPX772 has a current consumption of 3.1A and an operating temperature of 0-60 degrees Celsius.

IC200ALG262J differential current module

The IC200ALG322 module drives the transducer

IC200MDL240B Discrete input module

IC200MDL240B Distributed input/output

IC200MDL930 IC200MDL240B Output module

IC220PBI002 IC200ALG262J Network interface unit

IC609TCU1100B Programmable logic controller
