IC200CHS002  |  I/O載波模塊  用于快速組裝和連接到背板

　　模型:IC200CHS002

　　產品描述:I/O載波模塊

　　載體模塊樣式:盒式

　　尺寸高度:133.4毫米(5.25英寸)長度:66.80毫米(2.63英寸)

　　單根銅線尺寸:2.1 mm2 ~ 0.36 mm2

　　雙銅線尺寸:0.86mm2 Max

　　IC200CHS002是VersaMax I/O載波模塊。該模塊提供了一種模塊化的方法，因?yàn)樗试S維修，故障排除和更換I/O模塊，而無需拆除現有的終端。一般情況下，承載模塊除了提供承載模塊外，還提供安裝和現場布線的背板通信功能。

　　該模塊主要有36個端子，排列在A1 ~ A18和B1 ~ B18兩條帶上。該模塊與VersaMax同一產品系列中的32點I/O模塊或高密度I/O設備兼容。該模塊有4個公共/電源連接，并嵌入一個鍵控?fù)芴?hào)盤，該撥號盤被設置為與由I/O載波承載的模塊的指定鍵控位置相匹配。該硬件還配備了一個載波配對連接器，用于快速組裝和連接到背板。它還具有一個模塊鎖存鎖孔，用于將托管IO模塊鎖定到位。

　　IC200CHS002端子可承受的暫態電壓最高可達300vac。正常工作時，各端子的設計電壓范圍為0 ~ 264 VAC，各端子額定電流為2安培，各電源/公用端子容量為8安培。每個端子最多支持2根線的端接，單線連接的推薦線徑為awg# 14(平均橫截面2.1mm2)至awg# 22(平均橫截面0.36mm2)。awg# 18(平均橫截面0.86mm2)用于連接單個端子中的兩(2)根導線，使端子短路。

　　Model: IC200CHS002

　　Product Description: I/O carrier module

　　Carrier module style: box style

　　Dimensions Height: 133.4 mm (5.25 in) Length: 66.80 mm (2.63 in)

　　Size of a single copper wire: 2.1 mm2 to 0.36 mm2

　　Double copper wire size: 0.86mm2 Max

　　The IC200CHS002 is the VersaMax I/O carrier module. The module offers a modular approach as it allows for servicing, troubleshooting and replacement of I/O modules without removing existing terminals. Typically, the carrier module provides backplane communication functions for installation and field wiring as well as hosting modules.

　　The module primarily has 36 terminals arranged in two (2) strips labeled A1 to A18 and B1 to B18. The module is compatible with 32-point I/O modules or high-density I/O devices in the same VersaMax product family. The module has 4 public/power connections and is embedded with a keying dial that is set to match the specified keying position of the module hosted by the I/O carrier. The hardware also comes with a carrier pairing connector for quick assembly and connection to the backplane. It also features a module latch latch hole for locking the managed IO module into place.

　　The terminals of the IC200CHS002 can withstand transient voltages up to 300 VAC. During normal operation, the design voltage range of each terminal is 0-264 VAC, the current rating of each terminal is 2 amps, and the capacity of each power/common terminal is 8 amps. Each terminal supports the termination of up to 2 wires, and recommended wire sizes are AWG # 14 (average cross section 2.1mm2) to AWG #22 (average cross section 0.36mm2) for single wire connections. AWG #18 (average cross section 0.86mm2) is used to connect two (2) wires in a single terminal to short-circuit the terminal.
