IC693CPU360LT | 中央處理器 (CPU) 具有 RAM 和閃存
產品型號：IC693CPU360RR
工作溫度 0 至 60 攝氏度(32 至 140 華氏度)
儲存溫度 -40 至 85 攝氏度(-40 至 185 華氏度)
以太網端口數 不適用
內存存儲類型 RAM和閃存
典型掃描速率 每 1K 邏輯 0.22 毫秒(布爾觸點)
串行端口 RS-485(通過電源
電源要求 670 毫安，+5 VDC 電源供電
處理器類型 80386EX
用戶記憶 240K 字節
CPU類型 單插槽CPU模塊
產品描述
IC693CPU360RR 是一個中央處理器 (CPU) 360 模塊。它具有 240 KB 的可配置用戶內存。這是一個單插槽 CPU 模塊，在 8 個機架上具有 4096 個離散 I/O 點。CPU 360 模塊的典型掃描速率為每 1K 邏輯存儲器 0.22 mS。雖然該模塊沒有內置串行端口，但它可以使用 PLC 電源上的連接器。該模塊具有 RAM 和閃存，與其他 IC693 模塊一樣，它與固件 v.10.60 兼容。該裝置與 GE Fanuc 的 90-30 系列兼容。將此 CPU 與低 I/O 計數的入門級應用程序一起使用時，CPU 嵌入到背板中。這使得所有插槽都可用于輸入或輸出。以太網、各種總線模塊和控制設備是可以與此 CPU 模塊一起運行的一些兼容設備。
中端 CPU 型號是模塊化的，它們有各種內存大小可供選擇。該系列還包括具有不同性能和增強功能的型號，例如可編程協處理器模塊支持、覆蓋和電池備份時鐘。至于高性能CPU，它們基于最新的386EX處理器。這可實現快速計算和高吞吐量。這些模塊可以處理多達 4,096 個 I/O 點，它們從 32K 內存開始，并且可以用多種標準語言進行編程。IC693CPU360是高性能 CPU。
Product model: IC693CPU360RR
Operating temperature 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit)
Storage temperature -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit)
The number of Ethernet ports is not applicable
Memory Storage types RAM and flash
Typical scan rate 0.22 ms per 1K logic (Boolean contacts)
Serial port RS-485 (via power supply
Power supply required 670 MA, +5 VDC power supply
Processor type 80386EX
User memory 240K bytes
CPU Type Single-socket CPU module
Product description
The IC693CPU360RR is a central processing unit (CPU) 360 module. It has 240 KB of configurable user memory. This is a single-slot CPU module with 4096 discrete I/O points on eight racks. The typical scan rate for a CPU 360 module is 0.22 mS per 1K of logical memory. Although the module does not have a built-in serial port, it can use a connector on the PLC power supply. The module has RAM and flash memory, and like other IC693 modules, it is compatible with firmware v.10.60. The device is compatible with GE Fanuc's 90-30 series. When using this CPU with entry-level applications with low I/O counts, the CPU is embedded in the backplane. This makes all slots available for input or output. Ethernet, various bus modules, and control devices are some of the compatible devices that can run with this CPU module.
Mid-range CPU models are modular and they come in a variety of memory sizes to choose from. The family also includes models with different performance and enhancements, such as programmable coprocessor module support, overlay, and battery backup clock. As for high-performance cpus, they are based on the latest 386EX processors. This enables fast calculations and high throughput. These modules can handle up to 4,096 I/O points, they start with 32K of memory and can be programmed in multiple standard languages. The IC693CPU360 is a high-performance CPU.
