>>>>>型號:DS200ADGIH1AAA 輔助接口板 具有1個40針連接器
【功能描述】
DS200ADGIH1AAA技術規格
制造者GE通用電氣
系列馬克五世
零件編號DS200ADGIH1AAA
產品類型輔助接口板
GE輔助接口板DS200ADGIH1AAA具有1個40針連接器、60個跳線和一個6針連接器。GE輔助接口板DS200ADGIH1AAA還裝有多個測試點。該板的寬度為8英寸。DS200ADGIH1AAA的長度為6英寸，設計用于安裝在驅動器的板柜中。它有四個螺釘，它們與板架上的一個位置對齊，以便用螺釘安裝。
測試點提供了一種測試電路板上電路的方法。但是，只有合格的服務人員才能測試電路板。服務人員必須擁有針對任務進行校準和設計的測試設備。控件必須正確設置，探頭必須設計為與測試儀一起使用。將板子放在平坦的表面上，并在板子下面放一個保護袋。
此外由于存在靜電風險，服務人員必須始終佩戴腕帶。正確安裝腕帶后，腕帶的一端連接到您的手腕上，另一端夾在工作臺或辦公桌的金屬腿上。它也可以連接到其他金屬結構上。靜電被吸引到金屬地面上并離開電路板或您的身體。
減少靜電積聚的另一個適當步驟是避免在將電路板握在手中時四處走動。行走的摩擦導致靜電積聚。在涼爽干燥的天氣條件下尤其如此。如果沒有腕帶，您也可以將裝有板子的靜電袋觸摸到金屬結構上，例如椅子或金屬桌腿。
>>>>>型號:DS200ADGIH1AAA 輔助接口板 具有1個40針連接器
【英文介紹】
DS200ADGIH1AAA Technical specifications
Manufacturer GE General Electric
Series Mark V
Part number DS200ADGIH1AAA
Product Type Auxiliary interface board
The GE auxiliary interface board DS200ADGIH1AAA has one 40-pin connector, 60 jumpers, and one 6-pin connector. The GE auxiliary interface board DS200ADGIH1AAA is also equipped with multiple test points. The board is 8 inches wide. The DS200ADGIH1AAA has a length of 6 inches and is designed to be installed in the driver's board cabinet. It has four screws, which are aligned with a position on the board frame for mounting with screws.
A test point provides a method for testing a circuit on a board. However, only qualified service personnel can test the circuit board. Service personnel must have test equipment that is calibrated and designed for the task. The controls must be set up correctly and the probe must be designed to work with the tester. Place the board on a flat surface and place a protective bag under the board.
In addition, service personnel must always wear wristbands due to the risk of static electricity. When the wristband is properly installed, one end of the wristband is attached to your wrist and the other end clips to the metal leg of your workbench or desk. It can also be attached to other metal structures. Static electricity is attracted to the metal floor and leaves the circuit board or your body.
Another appropriate step to reduce static buildup is to avoid walking around while holding the board in your hands. The friction of walking causes static electricity to build up. This is especially true in cool, dry weather conditions. If you don't have a wristband, you can also touch the static bag with the board onto a metal structure, such as a chair or metal table leg.
