>>>>>型號:DS200IQXSG1AAA 逆變器緩沖板 具有8個端子連接器

【功能描述】

GE逆變器緩沖板DS200IQXSG1AAA具有8個端子連接器。端子標記為E1到E8。GE逆變器緩沖器板DS200IQXSG1AAA還包含1個8針連接器和1個安裝在板上的薄膜電容器。該板是安裝在板機柜中的多塊板之一。尺寸為6.25 x 5英寸，拐角處的四個孔與板架上的匹配安裝孔對齊。如果沒有新螺釘，請使用固定舊板的相同螺釘。

由于驅動器中的電路板和運動部件會產生熱量，因此在安裝驅動器時，冷卻是一個重要的考慮因素。變頻器必須具有可以自由流過變頻器的清潔空氣源，以將組件保持在允許的溫度范圍內。變頻器的設計使涼爽和清潔的空氣從底部進入變頻器，并通過變頻器內部上升。它繞過組件并越過組件，并將熱量從驅動器中帶走。

另一個考慮因素是，驅動器不要靠近其他產生熱量的設備，并且驅動器周圍的墻壁不會被墻壁另一側的設備加熱。

如果驅動器變得過熱并超過溫度范圍，則會檢測到溫度過高的情況，并且驅動器將自動停止。這種安全功能將防止損壞組件。它還可以防止火災危險的發展。

 >>>>>型號:DS200IQXSG1AAA 逆變器緩沖板 具有8個端子連接器

【英文介紹】

The GE Inverter buffer board DS200IQXSG1AAA has 8 terminal connectors. The terminals are labeled E1 to E8. The GE inverter buffer board DS200IQXSG1AAA also contains an 8-pin connector and a film capacitor mounted on the board. The board is one of several boards installed in the board cabinet. Measuring 6.25 x 5 inches, the four holes at the corner are aligned with the matching mounting holes on the plate rack. If no new screws are available, use the same screws that secured the old plate.

Because the circuit board and moving parts in the driver generate heat, cooling is an important consideration when installing the driver. The inverter must have a clean air source that can flow freely through the inverter to keep the components within the permitted temperature range. The inverter is designed so that cool and clean air enters the inverter from the bottom and rises through the inside of the inverter. It goes around the component and over the component and takes the heat away from the drive.

Another consideration is that the drive is not near other devices that generate heat, and that the walls around the drive are not heated by devices on the other side of the wall.

If the drive becomes overheated and exceeds the temperature range, an overheated condition will be detected and the drive will automatically stop. This safety feature will prevent damage to the components. It can also prevent the development of fire hazards.
