產品描述
General Electric Multilin 的 UR-8FH 是一款 CT/VT 模塊，設計用于安裝在通用繼電器系列中。它為繼電器提供 3-1A/5A 相電流互感器、1A/5A 接地電流互感器和四個電壓互感器端子。電流互感器和電壓互感器能夠?qū)㈦娏骱碗妷航档偷娇晒芾淼乃?，以便進行繼電器監測和控制，并且是為繼電器生成重要數據所必需的。
CT/VT 模塊可以在通道 1 到 4（含）或通道 5 到 8（含）上使用電壓或觸點輸入。UR手冊提供了有關正確繼電器連接的更多信息，指出了重要的細節，例如通道1和5如何連接到A相，通道2和6如何連接到B相等。這些手冊還向用戶提供了完整的警告和通知，例如，與繼電器端子的標稱電流為 1 A 或 5 A 的連接必須與所連接 CT 的次級額定值相匹配，以免用戶希望造成系統損壞?？傊?，用戶在開始進行繼電器連接過程之前仔細閱讀通用繼電器手冊非常重要。被描述為具有標準4CT/4VT功能。它沒有敏感的接地功能，這使得通用繼電器可以在被歸類為高阻抗的接地系統上受到保護。具有此功能的模塊還包括UR-8G、UR-8J、UR-8M和UR-8R訂購代碼。
>>>>>型號:UR8FH CT/VT 模塊 于安裝在通用繼電器系列中
【英文介紹】
Product description
General Electric Multilin's UR-8FH is a CT/VT module designed to be installed in the general purpose relay family. It provides the relay with 3-1A/5A phase current transformer, 1A/5A ground current transformer and four voltage transformer terminals. Current transformers and voltage transformers are able to reduce current and voltage to manageable levels for relay monitoring and control, and are necessary to generate important data for relays.
CT/VT modules can use voltage or contact inputs on channels 1 to 4 inclusive or channels 5 to 8 inclusive. The UR manual provides more information on proper relay connections, pointing out important details such as how channels 1 and 5 are connected to phase A, and channels 2 and 6 are connected equally to B. These manuals also provide the user with complete warnings and notifications, for example, that connections with A nominal current of 1 A or 5 A to the relay terminal must match the secondary rating of the connected CT, lest the user wish to cause system damage. In summary, it is important for users to read the general relay manual carefully before starting the relay connection process. Described as having standard 4CT/4VT functionality. It has no sensitive grounding function, which allows general purpose relays to be protected on ground systems classified as high impedance. Modules with this feature also include UR-8G, UR-8J, UR-8M, and UR-8R ordering codes.
