>>>型號:140NOE77111 以太網網絡模塊 用于工業自動化和控制系統

【功能描述】

140NOE77111是一款以太網網絡模塊，屬于Modicon Quantum系列。該模塊旨在實現Modicon Quantum PLC與以太網網絡上的其他設備之間的通信。

140NOE77111模塊包含以太網模塊的所有電子設備，并設計為模塊式，使用Modicon Quantum背板中的一個插槽，能夠占據背板中的任何插槽，并且支持熱插拔。該模塊在Modbus TCP/IP上具有分布式I/O特性，

采用總線或環形（銅纜或光纖）拓撲結構相互關聯。此外，該模塊還具有多種本地信令功能，包括數據速率選擇（10 Mbps或100 Mbps）、沖突檢測、下載模式、以太網模塊故障檢測、以太網網絡狀態顯示、全雙

工模式、模塊就緒狀態、網絡活動狀態、機架操作狀態以及傳輸活動狀態等。

140NOE77111模塊還具有高性能的特點，其高功率處理器優化了循環時間，同時集成了比之前更多的通信功能、診斷系統、存儲器靈活性和數據存儲能力。該模塊使用FTP（以太網端口）通信驅動程序，傳輸速率

為10/100 Mbit/s，并且功耗為2瓦。

總的來說，140NOE77111以太網網絡模塊是一款功能強大、性能穩定的網絡通信產品，適用于各種工業自動化和控制應用。

>>>>型號:140NOE77111 以太網網絡模塊 用于工業自動化和控制系統

【英文介紹】

The 140NOE77111 is an Ethernet network module that belongs to the Modicon Quantum family. The module is designed to enable communication between Modicon Quantum PLC and other devices on the Ethernet network.

The 140NOE77111 module contains all the electronics of the Ethernet module and is designed to be modular, using a single slot in the Modicon Quantum backplane, capable of occupying any slot in the backplane, and supports

hot swapping. The modules have distributed I/O characteristics over Modbus TCP/IP and are interrelated using a bus or ring (copper or fiber) topology. In addition, the module has a variety of local signaling functions, including

data rate selection (10 Mbps or 100 Mbps), collision detection, download mode, Ethernet module failure detection, Ethernet network status display, full duplex mode, module ready status, network activity status, rack operation

status, and transmission activity status.

The 140NOE77111 module also features high performance, with a high-power processor that optimizes cycle times while integrating more communication capabilities, diagnostic systems, memory flexibility and data storage

 capabilities than before. The module uses an FTP (Ethernet port) communication driver with a transfer rate of 10/100 Mbit/s and a power consumption of 2 watts.

Overall, the 140NOE77111 Ethernet network module is a powerful and stable network communication product for a variety of industrial automation and control applications.
