ATS48C14Q | 異步電機 | 用于風力發電廠和小型水電站等
制造者: 施耐德電氣
類型 : 系列軟起動器
型號：ATS48C14Q
產品應用場景:異步電機
應用領域:重工業和泵
保證 ：1年
異步電機，也稱為感應電機或交流異步電機，是一種常用的電動機類型。以下是關于異步電機的詳細介紹：
定義與原理：
ATS48C14Q 異步電機是由氣隙旋轉磁場與轉子繞組感應電流相互作用產生電磁轉矩，從而實現機電能量轉換為機械能量的一種交流電機。
其工作原理基于電磁感應現象，定子繞組加對稱電壓后，產生一個旋轉氣隙磁場，轉子繞組導體切割該磁場產生感應電勢，由于轉子繞組處于短路狀態會產生一個轉子電流。轉子電流與氣隙磁場相互作用就產生電磁轉矩，從而驅動轉子旋轉。
分類：
ATS48C14Q 異步電動機按照轉子結構分為兩種形式：鼠籠式(鼠籠式異步電機)和繞線式異步電動機。
根據用途和特性，還有防爆型三相異步電動機、YS系列三相異步電動機、Y、Y2系列三相異步電動機、YVP系列變頻調速電動機等多種類型。
特點：
結構簡單、制造容易、價格低廉、運行可靠、堅固耐用、運行效率較高。
ATS48C14Q 異步電機的轉速(轉子轉速)小于旋轉磁場的轉速，因此稱為異步電機。
異步電機在各類電動機中應用最廣、需要量最大，各國的以電為動力的機械中，約有90%左右為異步電動機。
應用：
三相異步電機主要用作電動機，拖動各種生產機械，如風機、泵、壓縮機、機床、輕工及礦山機械、農業生產中的脫粒機和粉碎機、農副產品中的加工機械等。
在家用電器中，如電風扇、洗衣機、電冰箱、空調器等也廣泛使用單相異步電動機。
異步電機也可作為發電機，用于風力發電廠和小型水電站等。
控制方法：
ATS48C14Q 異步電機的控制方法包括電流向量控制方法、空間矢量調制方法、直接轉矩控制方法和神經網絡控制方法等。
這些控制方法各有優缺點，可以根據實際需求選擇適合的控制策略，以實現異步電機的高效、穩定運行。
Manufacturer: Schneider Electric
Type: Series soft starter
Model: ATS48C14Q
Product application scenario: asynchronous motor
Applications: Heavy industry and pumps
Guarantee: 1 year
Asynchronous motors, also known as induction motors or AC asynchronous motors, are a commonly used type of motor. The following is a detailed introduction to asynchronous motors:
Definition and principle:
ATS48C14Q induction motor is a kind of AC motor which is generated by the interaction of the air gap rotating magnetic field and the induction current of the rotor winding to generate electromagnetic torque, so as to realize the conversion of electromechanical energy into mechanical energy.
Its working principle is based on the electromagnetic induction phenomenon. When the stator winding is applied with a symmetrical voltage, a rotating air gap magnetic field is generated. The conductor of the rotor winding cuts the magnetic field to generate an induced potential. The rotor current interacts with the air gap magnetic field to generate electromagnetic torque, which drives the rotor to rotate.
Categories:
The ATS48C14Q asynchronous motor is divided into two forms according to the rotor structure: squirrel cage (squirrel cage asynchronous motor) and wound asynchronous motor.
According to the use and characteristics, there are explosion-proof three-phase asynchronous motors, YS series three-phase asynchronous motors, Y, Y2 series three-phase asynchronous motors, YVP series variable frequency speed regulating motors and other types.
Features:
Simple structure, easy manufacturing, low price, reliable operation, durable, high operating efficiency.
The speed of the ATS48C14Q asynchronous motor (rotor speed) is less than the speed of the rotating magnetic field, so it is called an asynchronous motor.
Asynchronous motor is the most widely used in all kinds of motors, the largest demand, and about 90% of the electrically-powered machinery in various countries are asynchronous motors.
Applications:
Three-phase asynchronous motors are mainly used as motors to drive a variety of production machinery, such as fans, pumps, compressors, machine tools, light industry and mining machinery, threshers and shredders in agricultural production, processing machinery in agricultural and sideline products.
In household appliances, such as electric fans, washing machines, refrigerators, air conditioners, etc., single-phase asynchronous motors are also widely used.
Asynchronous motors can also be used as generators for wind power plants and small hydropower plants.
Control method:
The control method of ATS48C14Q induction motor includes current vector control method, space vector modulation method, direct torque control method and neural network control method.
Each of these control methods has its own advantages and disadvantages. The suitable control strategy can be selected according to the actual demand to realize the efficient and stable operation of the asynchronous motor.
