TRICONEX 8110 | PLC模塊 | 提供監控和診斷功能
產品型號：TRICONEX 8110
輸入電壓:24V DC
通信接口:以太網、RS485
數字輸入:16路
數字輸出:16路
模擬輸入:4
-模擬輸出:4
TRICONEX 8110 PLC模塊為控制和監控制造業，石油和天然氣以及發電等行業
的各種過程提供了靈活且可擴展的解決方案。它提供了與自動化系統的其他組件
的無縫集成，允許高效和同步的操作。
PLC模塊是指PLC系統中根據功能使用不同的各個部分的通俗叫法。以下是常見的PLC模塊及其功能：
電源模塊：TRICONEX 8110為PLC系統提供工作電源的單元部分，確保系統能夠正常工作。
CPU模塊：PLC系統的核心組成部分，包括中央處理器、存儲器和通信接口等部分。其主要功能包括接收來自輸入模塊的信號，按照預定的程序指令進行處理，并將處理結果發送到輸出模塊，控制外部設備。同時，還提供監控和診斷功能，如檢查程序執行狀態、診斷設備故障等。
輸入模塊：TRICONEX 8110用于采集外部信號，如傳感器信號、按鈕信號、開關信號等。輸入模塊一般包括輸入接口、信號處理電路和隔離電路等部分，將采集到的信號進行電平轉換和隔離處理，確保信號的正確性和可靠性，并將處理后的信號傳輸給CPU模塊，供其進行后續處理。
輸出模塊：TRICONEX 8110用于控制外部設備，如啟動電機、控制燈光、輸出報警信號等。輸出模塊一般包括輸出接口、驅動電路和隔離電路等部分，接收來自CPU模塊的控制信號，并根據信號指令進行相應的動作。通過輸出接口和驅動電路將控制信號轉換為能夠驅動外部設備的電平信號。
Product Model: TRICONEX 8110
Input voltage :24V DC
Communication interface: Ethernet, RS485
Digital input :16 channels
Digital output :16 channels
Analog input :4
- Analog output :4
TRICONEX 8110 PLC modules are designed to control and monitor industries such as manufacturing, oil and gas, and power generation
The various processes provide flexible and scalable solutions. It is provided with other components of the automation system
Seamless integration, allowing efficient and synchronous operations.
PLC module refers to the popular name of the various parts of the PLC system that use different functions. The following are common PLC modules and their functions:
Power Module: The TRICONEX 8110 provides the unit part of the working power supply for the PLC system to ensure that the system can work properly.
CPU module: the core part of the PLC system, including the central processor, memory and communication interface. Its main functions include receiving the signal from the input module, processing according to the predetermined program instructions, and sending the processing results to the output module, and controlling the external equipment. At the same time, it also provides monitoring and diagnosis functions, such as checking program execution status and diagnosing equipment faults.
Input module: The TRICONEX 8110 is used to collect external signals, such as sensor signals, button signals, switch signals, etc. The input module generally includes the input interface, the signal processing circuit and the isolation circuit, and so on. The collected signal is converted and isolated to ensure the correctness and reliability of the signal, and the processed signal is transmitted to the CPU module for subsequent processing.
Output module: The TRICONEX 8110 is used to control external devices, such as starting motors, controlling lights, and output alarm signals. The output module generally includes the output interface, the drive circuit and the isolation circuit, which receives the control signal from the CPU module and performs the corresponding action according to the signal instruction. Through the output interface and drive circuit, the control signal is converted to the level signal that can drive the external device.
