>>>型號:1756-L65 控制器 用于自動化系統 多種ControlLogix機箱兼容

【功能描述】

1756-L65是B系列ControlLogix控制器。這款控制器具有內置的RS-232串行端口，以及32MB的用于數據和邏輯的用戶存儲器和478KB的I/O存儲器。此外，它支持安裝可選的非易失性存儲器，但只能安裝128MB CompactFlash 1756-CF128存儲卡。

1756-L65的大模擬I/O為4000，大數字I/O，以及大總I/O為128,000。在5.1V DC時，它消耗1200mA的電流，而在24V DC時，它消耗14mA的電流。其功耗為3.5W，散熱為11.9 BTU/hr，并具有30V的連續隔離電壓。

1756-L65與多種ControlLogix機箱兼容，如1756-A4、1756-A7、1756-A10、1756-A13和1756-A17。其電池選擇也受到限制，只能使用1756-BA2鋰電池。

在設計和安裝方面，1756-L65的模塊化設計使得用戶可以獨立選擇I/O、端子類型和網絡接口。該系列還包括POINT Guard I/O安全級I/O模塊，這些模塊可在標準POINT I/O系統中并排使用。它的緊湊型設計使得在有限面板空間中進行安裝更為容易。

1756-L65支持多種網絡連通性，包括ControlNet、DeviceNet、EtherNet/IP及其他開放式網絡。它的可配置性和診斷功能使得POINT I/O易于應用。它還支持帶電插拔（RIUP），這意味著在系統運行期間可以更換模塊。同時，它既可以水平安裝也可以垂直安裝，無需降額。

>>>>型號:1756-L65 控制器 用于自動化系統 多種ControlLogix機箱兼容

【英文介紹】

The 1756-L65 is a B-series ControlLogix controller. The controller has a built-in RS-232 serial port, as well as 32MB of user memory for data and logic and 478KB of I/O memory. In addition, it supports the installation of

optional non-volatile memory, but can only install 128MB CompactFlash 1756-CF128 memory cards.

The 1756-L65 has a large analog I/O of 4000, a large digital I/O, and a large total I/O of 128,000. At 5.1V DC, it consumes 1200mA of current, while at 24V DC, it consumes 14mA of current. It has a power consumption

of 3.5W, heat dissipation of 11.9 BTU/hr, and a continuous isolation voltage of 30V.

The 1756-L65 is compatible with a variety of ControlLogix chassis, such as the 1756-A4, 1756-A7, 1756-A10, 1756-A13, and 1756-A17. Its battery options are also limited, with only 1756-BA2 lithium batteries available.

In terms of design and installation, the modular design of the 1756-L65 allows the user to independently choose I/O, terminal type and network interface. The family also includes POINT Guard I/O security-level I/O modules

 that can be used side-by-side in standard POINT I/O systems. Its compact design makes installation easier in limited panel space.

The 1756-L65 supports multiple network connectivity, including ControlNet, DeviceNet, EtherNet/IP, and other open networks. Its configurability and diagnostic capabilities make POINT I/O easy to apply. It also supports live

plug and plug (RIUP), which means that modules can be replaced while the system is running. At the same time, it can be installed both horizontally and vertically without derating.
