>>>型號:1769-IQ16 輸入模塊 用于工業自動化和控制系統 散熱性能
【功能描述】
1769-IQ16 是CompactLogix系列中的一款輸入模塊，它在工業自動化領域有著廣泛的應用。這款模塊具備多種功能特點，能夠滿足各種復雜的控制需求。
從性能參數上來看，1769-IQ16模塊具有出色的電氣特性。它擁有8毫秒的輸入OFF/ON信號延遲時間，在5.1伏直流電時消耗115mA電流。大關閉狀態電壓和額定電流分別為5伏DC和1.5mA，ON額定值為10V DC和2mA。
大浪涌電流為250mA，標稱輸入阻抗為3kW。這些參數保證了模塊在工業自動化系統中的高效穩定運行。
在機械特性方面，1769-IQ16模塊具有堅固耐用的設計。它重約270克，尺寸為118 x 35 x 87毫米，采用面板安裝方式。此外，它還具有IEC 2類增強絕緣類型，隔離電壓為75伏直流電，在1697伏直流電下進行了1秒鐘的測試
，保證了模塊在惡劣的工業環境下的穩定性和安全性。
在功能應用上，1769-IQ16模塊主要用于接收和處理來自各種傳感器和設備的輸入信號。它可以與其他CompactLogix系列的控制器和I/O模塊無縫集成，實現數據的實時采集、傳輸和處理。這使得它在生產線控制、機器人通信
、傳感器數據采集等多種場景中都能發揮重要作用。
1769-IQ16該模塊還具備優異的散熱性能。在開放式機箱中，其大散熱量為3.55W（每小時12.11 BTU），這有助于確保模塊在長時間運行過程中能夠保持穩定的溫度，避免因過熱而影響性能或壽命。
總的來說，1769-IQ16是一款功能強大、性能穩定的輸入模塊，適用于各種工業自動化應用場景。它不僅能夠滿足復雜的控制需求，還具有出色的電氣特性和機械特性，能夠在惡劣的工業環境下穩定運行。
>>>>型號:1769-IQ16 輸入模塊 用于工業自動化和控制系統 散熱性能
【英文介紹】
1769-IQ16 is an input module in the CompactLogix series, which has a wide range of applications in the field of industrial automation. This module has a variety of functional features to meet a variety of complex control needs.
From the point of view of performance parameters, the 1769-IQ16 module has excellent electrical characteristics. It has an input OFF/ON signal delay time of 8 milliseconds and consumes 115mA at 5.1 volts DC. The high shutdown
voltage and rated current are 5 volt DC and 1.5mA respectively, and ON ratings are 10V DC and 2mA. The large surge current is 250mA and the nominal input impedance is 3kW. These parameters ensure the efficient and stable
operation of the module in the industrial automation system.
In terms of mechanical properties, the 1769-IQ16 module has a rugged design. It weighs about 270 grams, measures 118 x 35 x 87 mm and is panel mounted. In addition, it has an IEC Class 2 enhanced insulation type with an isolation
voltage of 75 volts DC and a 1-second test at 1697 volts DC, guaranteeing the stability and safety of the module in harsh industrial environments.
In terms of functional applications, the 1769-IQ16 module is mainly used to receive and process input signals from various sensors and devices. It can be seamlessly integrated with other CompactLogix series controllers and I/O modules
to achieve real-time data acquisition, transmission and processing. This makes it play an important role in a variety of scenarios such as production line control, robot communication, sensor data acquisition, etc.
1769-IQ16 The module also has excellent thermal performance. In an open case, the maximum heat dissipation is 3.55W (12.11 BTU per hour), which helps to ensure that the module can maintain a stable temperature during long periods
of operation without affecting performance or life due to overheating.
Overall, the 1769-IQ16 is a powerful and stable input module for a wide range of industrial automation applications. It not only meets the complex control requirements, but also has excellent electrical and mechanical characteristics to
operate stably in harsh industrial environments.
