>>>>>型號:1756-EN2TR 基于機架的通信模塊 提供實時 I/O 通信和消息交換

【功能描述】

概覽

1756 EtherNet/IP 通信模塊

通過 EN4TR 和 EN4TRXT 通信模塊提供 CIP Security 協議

提供實時 I/O 通信和消息交換

使用現成的以太網通信芯片和物理介質

支持 128 或 256 個 Logix 連接

提供嵌入式交換機技術功能

通過 ControlLogix-XT? 通信模塊提供極端環境支持

使用安全通信模塊提供從控制系統到上層系統、編程終端和其他 ControlLogix 控制器的安全連接

提供設備級環網 (DLR) 連接，允許設備構成環形拓?fù)鋪硖峁┛蓮?fù)原性

為全冗余網絡基礎設施提供并行冗余協議 (PRP) 支持

1756 DeviceNet 通信模塊

使用通用工業協議 (CIP) 來控制、配置和收集工業級設備的數據

在簡單工業設備（傳感器和執行器）和高級設備（控制器和計算機）之間提供連接

支持 64 個節點

1756 ControlNet 通信模塊

使用通用工業協議 (CIP) 將 I/O 網絡和點對點網絡的功能相結合，為這兩項功能提供高速性能

為實時高吞吐量應用項目提供開放式控制網絡

為所有關鍵任務控制數據提供確定性的可重復傳輸

支持對時間無苛刻要求的數據傳輸

支持 64 或 128 個 Logix 連接以及 99 個節點

提供極端環境支持

1756 Data Highway Plus? 和遠程 I/O 通信模塊

支持設備間消息傳遞

遠程 I/O 鏈路連接遠程 I/O 機架和其他智能設備

遠程 I/O 功能使模塊充當掃描器，從而與遠程 I/O 設備相互傳輸數字量數據和塊傳送數據

支持 32 個 Logix 連接

支持在 DH+? 網絡上的設備間進行通信

1756 SynchLink 通信模塊

為分布式運動和協調驅動控制提供時間同步和數據廣播

將 ControlLogix 機架連接到 SynchLink? 光纖通信連接

允許控制器使用其他機架中某個控制器的運動軸數據

敷形涂覆

目前在部分 ControlLogix? 產品上提供了敷形涂覆，以幫助針對惡劣環境為自動化系統提供保護。Rockwell Automation 在 ISA G3 A 組分類環境中，對這些產品進行了相當于 10 年使用期的測試。這些產品由產品目錄號中的“K”后綴來標識，它們

幫助對電路進行保護，防止其暴露于污染、潮濕、溫度變化、鹽霧、有機腐蝕（霉菌）和腐蝕性化學品和蒸汽

可長期保持絕緣電阻 (SIR)，從而確保裝置的運行完整性，在腐蝕性環境中使用時具有較長的產品生命周期

 >>>>>型號:1756-EN2TR 基于機架的通信模塊 提供實時 I/O 通信和消息交換

【英文介紹】

overview

1756 EtherNet/IP communication module

The CIP Security protocol is provided through the EN4TR and EN4TRXT communication modules

Provides real-time I/O communication and message exchange

Use off-the-shelf Ethernet communication chips and physical media

Supports 128 or 256 Logix connections

Provides embedded switch technology functions

Extreme environment support via the ControlLogix-XT? communication module

Provide secure connections from the control system to the upper layer systems, programming terminals, and other ControlLogix controllers using the secure communication module

Provides device level ring network (DLR) connectivity, allowing devices to form a ring topology to provide resilience

Parallel Redundancy Protocol (PRP) support for fully redundant network infrastructure

1756 DeviceNet communication module

Use the Common Industrial Protocol (CIP) to control, configure and collect data from industrial-grade equipment

Provides connectivity between simple industrial equipment (sensors and actuators) and advanced equipment (controllers and computers)

Supports 64 nodes

1756 ControlNet Communication module

The Common Industrial Protocol (CIP) is used to combine the functions of I/O networks and peer-to-peer networks, providing high-speed performance for both functions

Provides open control network for real-time high throughput application projects

Provide deterministic, repeatable transmission of all mission-critical control data

Supports time-free data transmission

Supports 64 or 128 Logix connections and 99 nodes

Provide extreme environment support

1756 Data Highway Plus? and remote I/O communication module

Supports message transfer between devices

Remote I/O links Connect remote I/O racks and other smart devices

The remote I/O function enables the module to act as a scanner to transfer digital and block transfer data to and from remote I/O devices

Supports 32 Logix connections

Supports communication between devices on a DH+? network

1756 SynchLink communication module

Provides time synchronization and data broadcasting for distributed motion and coordinated drive control

Connect the ControlLogix rack to the SynchLink? fiber optic communications connection

Allows the controller to use the axis of motion data of a controller in another rack

Shape coating

Form coatings are currently available on some ControlLogix? products to help protect automation systems against harsh environments. Rockwell Automation tested these products in the ISA G3 Group A classification environment for the equivalent of 10 years of use. These products are identified by the "K" suffix in the product catalog number, which

Helps protect circuits from exposure to pollution, moisture, temperature changes, salt spray, organic corrosion (mold) and corrosive chemicals and vapors

Insulation resistance (SIR) is maintained for a long time to ensure the operational integrity of the unit and has a long product life cycle when used in corrosive environments
