>>>>>型號:AN-X2-AB-DHRIO 遠程 I/O 或 DH+ 網關
【功能描述】
規格
遠程I/O掃描器功能：
此模式允許用戶用ControlLogix或CompactLogix PAC替換現有的遠程I/O PLC，而無需更換現有的I/O機架。
在不中斷現有控制的情況下構建新的控制器程序，最大限度地減少停機時間
支持多達32個機架的遠程I/O
支持所有遠程I/O波特率（57.6、115.2和230.4 K波特率）和0至76八通道的遠程I/O尋址
適用于ControlLogix或CompactLogix
自動配置實用程序可發現波特率并映射離散I/O，從而減少配置錯誤
駕駛：
此模式支持將遠程I/O上的傳統Allen Bradley驅動器升級到啟用了EtherNet/IP的新驅動器。
無需更改PLC代碼
支持多達4個EtherNet/IP驅動器
可配置1/4、1/2和全機架尋址
支持EtherNet/IP上的所有PowerFlex變頻器
人機界面
此模式允許將遠程I/O或DH+上的傳統PanelView升級為EtherNet/IP上的PanelView Plus、PanelView Plus 6或PanelView Plus 7。
無需更改PLC代碼
在同一網絡上支持多達8個PanelView
支持PLC5或SLC網絡上的DH+到EtherNet/IP PanelViews升級
DH+型
這種操作模式充當EtherNet/IP和Data Highway Plus網絡之間的橋梁。
EtherNet/IP網絡上的編程終端和/或處理器可以訪問DH+網絡上的傳統處理器
通過RSLinx下載到PLC5或SLC
通過Web瀏覽器進行配置
支持所有DH+波特率（57.6、115.2和230.4 K波特）
支持PLC5或SLC網絡上的DH+到EtherNet/IP PanelViews升級
Flex I/O掃描器
此模式允許遠程I/O上的PLC連接和控制1794-AENT EtherNet/IP Flex適配器。
設計用于替換過時的1794-ASB適配器
支持多達16個EtherNet/IP連接
每個適配器和離散機架都算作一個連接。每個模擬模塊都算作一個連接
>>>>>型號:AN-X2-AB-DHRIO 遠程 I/O 或 DH+ 網關
【英文介紹】
specification
Remote I/O Scanner Features:
This mode allows users to replace existing remote I/O PLCS with ControlLogix or CompactLogix PAC without having to replace existing I/O racks.
Build new controller programs without interrupting existing controls to minimize downtime
Supports up to 32 racks of remote I/O
Supports all remote I/O baud rates (57.6, 115.2, and 230.4K baud rates) and remote I/O addressing from 0 to 76 eight channels
Available for ControlLogix or CompactLogix
The auto-configuration utility discovers baud rates and maps discrete I/O to reduce configuration errors
Driving:
This mode allows you to upgrade a legacy Allen Bradley drive on remote I/O to a new drive with EtherNet/IP enabled.
No need to change the PLC code
Supports up to 4 EtherNet/IP drives
1/4, 1/2, and full rack addressing are available
All PowerFlex drives on EtherNet/IP are supported
Man-machine interface
This mode allows you to upgrade a traditional PanelView on remote I/O or DH+ to PanelView Plus, PanelView Plus 6, or PanelView Plus 7 on EtherNet/IP.
No need to change the PLC code
Up to 8 PanelViews are supported on the same network
DH+ to EtherNet/IP PanelViews upgrades are supported on PLC5 or SLC networks
DH+ type
This mode of operation acts as a bridge between EtherNet/IP and Data Highway Plus networks.
Programming terminals and/or processors on EtherNet/IP networks can access traditional processors on DH+ networks
Download to PLC5 or SLC via RSLinx
You can configure this parameter using the Web browser
Support for all DH+ baud rates (57.6, 115.2 and 230.4K baud)
DH+ to EtherNet/IP PanelViews upgrades are supported on PLC5 or SLC networks
Flex I/O scanner
This mode allows a PLC on remote I/O to connect and control the 1794-AENT EtherNet/IP Flex adapter.
Designed to replace the outdated 1794-ASB adapter
Supports up to 16 EtherNet/IP connections
Each adapter and discrete rack counts as one connection. Each analog module counts as a connection
