>>>>>型號:MS-NAE5510 網絡自動化引擎(NAE)和網絡

【功能描述】

應用程序

網絡自動化引擎(NAE)和網絡

集成引擎(NIE)是支持web的，

基于以太網的監控設備，用于監控和

現場級樓宇自動化控制網絡

設備，暖通空調設備和照明。圖1

為典型的NAE55型號。

本文檔介紹MS-NAE55xx-x的安裝方法

MS-NIE55xx-x型發動機，參考

，除非另有規定，否則統稱為NAE55。

北美排放法規

安裝

安裝NAE55時，請遵循以下原則:

?將NAE55裝在原集裝箱中運輸至

盡量減少振動和沖擊對設備的損壞

NAE55。

?確認所有隨NAE55發貨的部件。

數據保護電池和NAE55船

放在一起，但分開包裝。

?請勿將NAE55掉落或?qū)ζ溥M(jìn)行物理處理

沖擊。

?請勿打開NAE55外殼(數據除外)

保護電池艙)。NAE55有

內部沒有用戶可維修的部件。

部分包括

?1個NAE55

?一個數據保護電池

?一份安裝說明書

所需材料和專用工具

?四個適合安裝表面的緊固件

(M4螺絲-歐洲，8號螺絲-北美)

?兩個36厘米(14英寸)或更長件的DIN導軌

僅適用于DIN導軌安裝

?用于固定的小直刃螺絲刀

接線端子中的通信導線

 >>>>>型號:MS-NAE5510 網絡自動化引擎(NAE)和網絡

【英文介紹】

Application program

Network Automation Engine (NAE) and networking

The Integration Engine (NIE) is web-enabled,

Ethernet-based monitoring device for monitoring and

Field level building automation control network

Equipment, HVAC equipment and lighting. Figure 1

Typical NAE55 model.

This document describes how to install MS-NAE55xx-x

MS-NIE55xx-x engine, ref

Unless otherwise specified, they are collectively referred to as NAE55.

North American emission regulations

Install

When installing NAE55, observe the following principles:

? NAE55 will be shipped in the original container to

Minimize vibration and shock damage to the equipment

NAE55.

? Confirm all components shipped with NAE55.

Data protection battery and NAE55 boat

Put them together, but pack them separately.

? Do not drop or physically handle NAE55

Shock.

? Do not open NAE55 shell (except data)

Protect the battery compartment). NAE55 Yes

There are no user repairable parts inside.

Part includes

?1 NAE55

? A data protection battery

? A copy of the installation manual

Materials and special tools required

? Four fasteners suitable for mounting surfaces

(M4 screws - Europe, No. 8 screws - North America)

? Two DIN guides for 36 cm (14 in) or longer pieces

Suitable for DIN rail installation only

? Small straight blade screwdriver for fixing

The communication wire in the terminal
