>>>>>型號:MVI56-PDPMV1 主站網絡接口模塊 從站設備進行通信

【功能描述】

MVI56 PROFIBUS DP-V1 主站網絡接口模塊允許 ControlLogix 處理器輕松與支持 PROFIBUS DP-V0 和 DP-V1 協議的從站設備進行通信。該模塊充當PROFIBUS網絡和處理器之間的輸入/輸出模塊，支持符合IEC 61158的完整主站規范。

特點和優勢

該模塊支持符合 IEC 61158 的完整主規范。非循環參數數據可以通過 1 類或 2 類 DPV1 服務傳輸，使處理器能夠輕松地與支持 PROFIBUS DPV0/V1 協議的從設備進行通信。

該模塊充當PROFIBUS網絡和ControlLogix處理器之間的輸入/輸出模塊。來自處理器的數據傳輸與PROFIBUS網絡上的I/O數據傳輸是異步的。數據庫由用戶定義并存儲在模塊中，以保存協議所需的數據。

規格

單插槽 - 兼容 1756 背板

該模塊被識別為輸入/輸出模塊，并可以訪問處理器內存，以便在處理器和模塊之間傳輸數據

梯形邏輯用于模塊和處理器之間的數據傳輸。包括示例梯形圖文件（附加說明）。

本地或遠程機架

可配置的 I/O 背板尺寸可為遠程機架應用提供最佳性能

已啟用 CIPconnect?。模塊支持使用羅克韋爾自動化以太網接口通過以太網路由與 ProSoft Configuration Builder 和 FDT comDTM 進行通信。

 >>>>>型號:MVI56-PDPMV1 主站網絡接口模塊 從站設備進行通信

【英文介紹】

The MVI56 PROFIBUS DP-V1 master network interface module allows the ControlLogix processor to easily communicate with slave devices that support the PROFIBUS DP-V0 and DP-V1 protocols. The module acts as an input/output module between the PROFIBUS network and the processor, supporting the complete master station specification according to IEC 61158.

Characteristics and advantages

The module supports the complete master specification conforming to IEC 61158. Acyclic parameter data can be transmitted via Class 1 or Class 2 DPV1 services, enabling the processor to easily communicate with slave devices that support the PROFIBUS DPV0/V1 protocol.

This module acts as an input/output module between the PROFIBUS network and the ControlLogix processor. The data transfer from the processor is asynchronous with the I/O data transfer on the PROFIBUS network. The database is defined by the user and stored in the module to hold the data required by the protocol.

specification

Single slot - Compatible with 1756 backplane

The module is recognized as an input/output module and has access to processor memory to transfer data between the processor and the module

Ladder logic is used for data transfer between modules and processors. Includes a sample ladder diagram file (additional instructions).

Local or remote rack

Configurable I/O backplane sizes provide optimal performance for remote rack applications

CIPconnect? is enabled. The module supports communication with ProSoft Configuration Builder and FDT comDTM via Ethernet routing using the Rockwell Automation Ethernet interface.
