>>>>>型號:AN-X2-AB-DHRIO 遠程I/O系統 I/O支架
【功能描述】
Remote I/O Scanner Features:
模式支持升級舊版本的Allen Bradley遠程I/O系統轉換成ControlLogix 或者CompactLogix 系列PAC而無需替代已存在的I/O支架。
建立新系統無需中斷已存在控制, 減少停機時間
最多支持32個遠程I/O機架
支持所有遠程I/O波特率(57.6, 115.2, and 230.4 K baud), 遠程I/O地址從0至76
兼容ControlLogix和CompactLogix系統
自動配置軟件搜索波特率分配離散I/O降低配置風險
Drive:
模式支持升級舊版本的Allen Bradley遠程I/O驅動轉換成EtherNet/IP驅動。
無需改變PLC 代碼
最多支持4路以態網驅動
可配置1 / 4，1 / 2和全機架尋址
支持PowerFlex驅動以態網通訊
HMI
模式支持升級舊版本的Allen Bradley遠程I/O驅動轉換成PanelView Plus, PanelView Plus 6 或者 PanelView Plus 7 EtherNet/IP
無需改變PLC 代碼
在同一網段最多支持8臺PanelViews
支持在PLC5 or SLC網絡中將DH+ 轉換升級成EtherNet/IP PanelViews
DH+
模式支持EtherNet/IP和DH+網絡之間的協議轉換
支持EtherNet/IP的可編程終端, 或者處理器能夠連接 DH+網絡的處理器
通過RSLinx 下載到PLC5或者SLC
通過網絡瀏覽器配置
支持所有DH+波特率(57.6, 115.2, 和 230.4 K baud)
支持EtherNet/IP的可編程終端, 或者處理器能夠連接 DH+網絡的處理器
支持在PLC5 or SLC網絡中將DH+ 轉換升級成EtherNet/IP PanelViews
Flex I/O Scanner
模式支持Allen Bradley遠程I/O系統和1794-AENT EtherNet/IP Flex適配器之間的通訊
Des替代1794-ASB 適配器
最多支持16個 EtherNet/IP 連接
每個適配器和分離機架做為一個連接。 每個模擬量模塊做為一個連接
>>>>>型號:AN-X2-AB-DHRIO 遠程I/O系統 I/O支架
【英文介紹】
Remote I/O Scanner Features:
Mode supports upgrading older versions of Allen Bradley remote I/O systems to ControlLogix or CompactLogix series PACs without replacing existing I/O mounts.
Build new systems without interrupting existing controls, reducing downtime
Supports up to 32 remote I/O racks
Supports all remote I/O baud rates (57.6, 115.2, and 230.4 K baud), and remote I/O addresses from 0 to 76
Compatible with ControlLogix and CompactLogix systems
Automatic configuration software searches for baud rates and allocates discrete I/ OS to reduce configuration risks
Drive:
The mode supports upgrading the Allen Bradley remote I/O driver of an earlier version to an EtherNet/IP driver.
No need to change the PLC code
Supports a maximum of four state network drivers
1/4, 1/2 and full rack addressing are available
Support PowerFlex driver to state network communication
HMI
The mode supports upgrading the Allen Bradley remote I/O driver of an earlier version to PanelView Plus, PanelView Plus 6, or PanelView Plus 7 EtherNet/IP
No need to change the PLC code
A maximum of eight PanelViews can be configured on the same network segment
DH+ conversion to EtherNet/IP PanelViews is supported on PLC5 or SLC networks
DH+
Mode Supports protocol conversion between EtherNet/IP and DH+ networks
A programmable terminal that supports EtherNet/IP, or a processor that can connect to a DH+ network
Download to PLC5 or SLC via RSLinx
Set this parameter using a web browser
Support for all DH+ baud rates (57.6, 115.2, and 230.4 K baud)
A programmable terminal that supports EtherNet/IP, or a processor that can connect to a DH+ network
DH+ conversion to EtherNet/IP PanelViews is supported on PLC5 or SLC networks
Flex I/O Scanner
The mode supports communication between the Allen Bradley remote I/O system and the 1794-AENT EtherNet/IP Flex adapter
Des replaces the 1794-ASB adapter
Up to 16 EtherNet/IP connections are supported
Each adapter and separate rack act as a connection. Each analog module acts as a connection
