3BHE039724R0C3D PPD513AOC-100440 \ 集成柵極換向晶體管
型號：3BHE039724R0C3D PPD513AOC-100440
類別：集成柵極換向晶體管
質保：365天
貨期：3-5天/周
產品凈厚度/長度：114.3 毫米
通信協議：PROFIBUS DP
傳輸速率：960 kbps、1.5 Mbps、3 Mbps
節點地址：0 至 255
電源電壓：24 VDC
功耗：< 5 W
3BHE039724R0C3D PPD513AOC-100440 集成柵極換向晶體管(IGCT)是一種先進的電力半導體器件，以下是關于它的詳細介紹：
定義與結構：
集成柵極換流晶閘管(Intergrated Gate Commutated Thyristors，簡稱IGCT)是1996年問世的新型電力半導體器件，專為巨型電力電子成套裝置設計。
它基于GTO(門極可關斷晶閘管)結構，并采用了集成柵極結構進行柵極硬驅動，同時結合了緩沖層技術及陽極透明發射極技術。
特點與優勢：
IGCT結合了晶閘管的通態特性和晶體管的開關特性，擁有低通態壓降、高阻斷電壓和穩定的開關特性。
由于采用了緩沖結構和淺層發射極技術，IGCT的動態損耗降低了約50%。
在一個芯片上集成了具有良好動態響應的續流二極管，實現了晶閘管與晶體管的性能有機結合。
應用與影響：
3BHE039724R0C3D PPD513AOC-100440 IGCT使得變流裝置在功率、可靠性、開關速度、效率、成本、體積和重量等方面取得了顯著進步，為電力電子成套裝置帶來了革新。
該器件具有電流大、電壓高、開關頻率高、可靠性高等特點，同時結構緊湊、損耗低，且制造成本低、成品率高，顯示出良好的應用前景。
Model: 3BHE039724R0C3D PPD513AOC-100440
Category: Integrated gate commutator transistor
Warranty: 365 days
Delivery time: 3-5 days/week
Net product thickness/length: 114.3 mm
Communication protocol: PROFIBUS DP
Transmission rate: 960 kbps, 1.5 Mbps, 3 Mbps
Node addresses: 0 to 255
Power supply voltage: 24 VDC
Power consumption: < 5 W
3BHE039724R0C3D PPD513AOC-100440 Integrated gate commutator transistor (IGCT) is an advanced power semiconductor device, the following is a detailed introduction about it:
Definition and structure:
Intergrated Gate Commutated Thyristors (IGCT) are a new type of power semiconductor device introduced in 1996, designed for large power electronics packages.
It is based on GTO (gate turn-off thyristor) structure, and adopts integrated gate structure to drive the gate hard, combined with buffer layer technology and anode transparent emitter technology.
Features and advantages:
The 3BHE039724R0C3D PPD513AOC-100440 IGCT combines the on-state characteristics of thyristors and the switching characteristics of transistors, with low on-state voltage drop, high blocking voltage and stable switching characteristics.
Because of the buffer structure and shallow emitter technology, the dynamic loss of IGCT is reduced by about 50%.
The continuous current diode with good dynamic response is integrated on a chip, and the performance of thyristor and transistor is organically combined.
Application and impact:
The 3BHE039724R0C3D PPD513AOC-100440 IGCT has made significant progress in terms of power, reliability, switching speed, efficiency, cost, volume and weight, and has brought innovation to power electronics packages.
The device has the characteristics of high current, high voltage, high switching frequency, high reliability, compact structure, low loss, low manufacturing cost, high yield, and shows a good application prospect.
