>>>>>型號:A6410 雙通道位置和殼膨脹監測模塊 機械膨脹裝置
【功能描述】
CSI 6500機器狀態監控對應于完全符合API 670并為保護和關鍵、旋轉監測機器。特殊技能該系統的數據集成中的保護功能過程自動化DeltaV只有三個簡單的鼓掌步驟，瞬態分析現場演示、錄制、，暫停和播放，以及優秀的PeakVue用于早期檢測的處理滾動軸承損壞和驅動的配置
裝配托架：
-19“裝配托架僅適用于保護功能為6-U版本以及標準3HE版本。
-19“裝配托架僅適用于6U中的預測功能安裝高度前部或后部傳感器接線板。此外，還有一個7.5英寸緊湊型可用的安裝寬度。
-用于組合保護功能和預測僅19“/6 HE使用了裝配托架。
完整機器監控功能API 670順從的
n機柜安裝用標準19“/6 HE模塊托架
n系統設計確保在卡出現故障時超過兩個頻道受到影響待更換
n內部時鐘與系統主時鐘同步
透平型膨脹機原理圖
以氣體膨脹時速度能的變化來傳遞能量的膨脹機。這種膨脹機有單級和雙級、立式和臥式、沖動式和反動式之分。一般采用單級向心徑流反動式，傳出的外功由發電機、鼓風機或油制動器所吸收。它近似于單級離心壓縮機，但具有調節進氣量用的（可調葉片）導流器。低速軸承用油強制潤滑，高速的采用氣體軸承。透平膨脹機由于有噴嘴損失、葉輪損失、余速損失、輪盤摩擦損失、泄漏損失、竄流損失和外熱侵入損失，一般絕熱效率為：中壓膨脹機65～75%，低壓膨脹機75～85%。60年代已制成帶液膨脹機，大多用于天然氣分離設備。
>>>>>型號:A6410 雙通道位置和殼膨脹監測模塊 機械膨脹裝置
【英文介紹】
CSI 6500 machine condition monitoring corresponds to fully API 670 compliant and protected and critical, rotational monitoring machines. The system's data integration in the protection function process automation DeltaV has only three simple clapping steps, transient analysis live demonstration, recording, pause and playback, as well as the excellent PeakVue for early detection of handling rolling bearing damage and drive configuration
Assembly bracket:
-19 "Assembly brackets are only available for 6-U versions with protection functions and standard 3HE versions.
-19 "Assembly brackets are only suitable for predictive function mounted height front or rear sensor patch panels in 6U. In addition, a 7.5-inch compact is available with a mounting width.
- For combining protection functions and predicting only 19 "/6 HE uses an assembly bracket.
Full machine monitoring functionality API 670 compliant
n Standard 19 "/6 HE module tray for cabinet installation
The system design ensures that more than two channels are affected to be replaced in the event of a card failure
n Synchronize the internal clock with the system master clock
Schematic diagram of turbo-type expansion machine
An expander that transmits energy by changing the velocity energy of a gas as it expands. The expander is divided into single stage and double stage, vertical and horizontal, impulse and reaction type. Generally, single-stage radial flow reaction type is used, and the outgoing external work is absorbed by the generator, blower or oil brake. It is similar to a single-stage centrifugal compressor, but has a (adjustable blade) deflector for regulating the intake volume. Low speed bearing oil forced lubrication, high speed using gas bearings. Turbine expander due to nozzle loss, impeller loss, residual speed loss, disc friction loss, leakage loss, channeling loss and external thermal intrusion loss, the general adiabatic efficiency is: 65 ~ 75% of the middle pressure expansion machine, low pressure expansion machine 75 ~ 85%. In the 1960s, it was made into a liquid expansion machine, mostly used in natural gas separation equipment.
