>>>>>型號:IC200PWR001 提供背板電源

【功能描述】

IC200PWR001是一個24VDC電源， 為CPU、NIU和I/O模塊提供背板電源。

IC200PWR001可以通過3.3伏和5伏輸出提供最大1.5安培的輸出電流,

3.3伏輸出最高0.25安培。如果IC200PWR001安裝在CPU或NIU上,則可將其視為站的主電源。IC200PWR001安裝在電源升壓器托架 上時,也可用

作補充電源。

IC200PWR001的輸入電壓為18至30VDC, 標(biāo)稱電壓為24VDC,輸入功率為11瓦。IC200PWR001的保持時間為10ms, 浪涌電流在24VDC時為20A,在30VDC時為25A。

IC200PWR001的輸出電壓為5VDC, 3.3VDC。 最大總輸出電流不應(yīng)超過1.5a。IC 200 PWR 001提供短路、過載和反極性保護。接線時，DC-必須接地至機架/大地。

DC 接地到電源的內(nèi)部框架,這意味著不應(yīng)該使用浮動電源。

>>>>>型號:IC200PWR001 提供背板電源

【英文介紹】

The IC200PWR001 is a 24VDC power supply that provides backplane power for CPU, NIU, and I/O modules.

The IC200PWR001 can provide a maximum output current of 1.5 amps through 3.3 volts and 5 volts outputs.

3.3 volts output up to 0.25 amps. If IC200PWR001 is installed on a CPU or NIU, it can be considered the main power supply for the station. The IC200PWR001

is also available when mounted on a power booster bracket

To supplement the power supply.

The IC200PWR001 has an input voltage of 18 to 30VDC, a nominal voltage of 24VDC, and an input power of 11 watts. IC200PWR001 has a hold time of 10ms and

an inrush current of 20A at 24VDC and 25A at 30VDC. The output

voltage of IC200PWR001 is 5VDC, 3.3VDC. The maximum total output current should not exceed 1.5a. The IC 200 PWR 001 provides short circuit, overload and

reverse polarity protection. When connecting cables, the DC- must be

grounded to the rack/ground. The DC is grounded to the internal frame of the power supply, which means that floating power should not be used.
