IC693PBM200 | 主模塊 | 90-30 系列控制器


　IC693BPM200 是一個 Profibus 主模塊，是 90-30 系列控制器平臺的一部分，該平臺以前來自 GE Fanuc，現在被 Emerson Automation 收購。該模塊是支持Profibus通信協議的可選通信模塊。它帶有一 (1) 個 Profibus Master 端口，支持以菊花鏈拓撲形式與 Profibus 網絡通信，另一個 RS232 服務端口可用于下載配置和固件升級。

　　IC693BPM200是一個單插槽模塊，可安裝到 CPU 底板、擴展或遠程底板。它支持多達 125 個 Profibus DP 從站的通信，從而實現遠程 I/O 架構并與其他設備(如網關、HMI、SCADA 和其他設備)進行通信。對于遠程 I/O 功能，每個 Profibus 從站能夠接收 244 字節的輸入數據并發送 244 字節的輸出數據。它支持同步和凍結配置，并可配置為從 9600 Kbaud 到 12MBaud 的所有 Profibus 標準傳輸速率。它遵循菊花鏈拓撲結構，因為該協議源自 RS485 電氣標準，其兩端(特別是網絡的節點 1 和最后一個節點)通過終端電阻閉合。它還帶有 SYS 和 COM 狀態 LED，用于描述活動通信和設備操作。

　　此模塊使用 CIMPLICITY Machine Edition Logic Developer 2.6 或更高版本進行配置。它可以與 90-30 系列 CPU 一起使用，例如 CPU 311/313/323、331、341,350、352、360、363、363 和 364。對于大多數應用和控制系統，此模塊適用的 CPU 版本為 V8.00，但如果打算用于大型應用，則可能需要 CPU 版本 10.60 或更高版本。

　　GE Fanuc IC693PBM200 Profibus DP 主模塊通信卡是一種固態通信卡，專為 GE 90-30 系列可編程邏輯控制器而設計和制造。它作為PLC和PROFIBUS DP網絡之間的主要通信接口，使PLC能夠連接到網絡并與現場設備、其他控制器、通信平臺和許多其他類型的設備建立數據交換。使用該模塊，可以從單個Fanuc PLC控制多達125個PROFIBUS DP從站單元，該模塊能夠從網絡接收244字節的輸入，并發送244字節的輸出命令作為響應。


　　The IC693BPM200 is a Profibus master module that is part of the 90-30 series controller platform, formerly from GE Fanuc and now acquired by Emerson Automation. This module is an optional communication module that supports Profibus communication protocol. It comes with one (1) Profibus Master port that supports communication with the Profibus network in a Daisy chain topology, and another RS232 service port that can be used to download configurations and firmware upgrades.

　　The IC693BPM200 is a single-slot module that can be installed on CPU backboards, extensions, or remote backboards. It supports communication of up to 125 Profibus DP slaves, enabling remote I/O architectures and communication with other devices such as gateways, Hmis, SCADA, and others. For remote I/O functions, each Profibus slave station is capable of receiving 244 bytes of input data and sending 244 bytes of output data. It supports sync and freeze configurations and can be configured for all Profibus standard transfer rates from 9600 Kbaud to 12MBaud. It follows a Daisy chain topology, as the protocol is derived from the RS485 electrical standard, and its two ends (especially node 1 and the last node of the network) are closed by terminal resistors. It also comes with SYS and COM status leds for describing active communication and device operation.

　　This module is configured using CIMPLICITY Machine Edition Logic Developer 2.6 or later. It can be used with 90-30 series cpus, such as cpus 311/313/323, 331, 341,350, 352, 360, 363, 363, and 364. For most applications and control systems, the CPU version for this module is V8.00, but if you intend to use it for large applications, you may need CPU version 10.60 or higher.

　　The GE Fanuc IC693PBM200 Profibus DP Master Module communication card is a solid-state communication card designed and manufactured for the GE 90-30 series programmable logic controllers. It acts as the main communication interface between the PLC and the PROFIBUS DP network, enabling the PLC to connect to the network and establish data exchange with field equipment, other controllers, communication platforms and many other types of equipment. Up to 125 PROFIBUS DP slave station units can be controlled from a single Fanuc PLC using the module, which is capable of receiving 244 bytes of input from the network and sending 244 bytes of output commands in response.
