IC693CMM321 - 90-30 系列以太網接口模塊
IC693CMM321 以太網接口模塊是一種網絡通信設備，它通常配備標準的RJ45以太網接口和RS232/485串口，以確保與各類PLC設備的兼容連接。該模塊的主要功能包括實時數據采集、支持工業標準協議以及與其他設備和系統的無縫集成。
IC693CMM321 以太網接口電路主要由MAC控制器和物理層接口(PHY)兩大部分構成。一般32位處理器內部實際上已包含了以太網MAC控制，但并未提供物理層接口，因此需外接一片物理層芯片以提供以太網的接入通道。以太網物理層接口器件的主要功能包括物理編碼子層、物理媒體附件、雙絞線物理媒體子層、10BASE-TX編碼/解碼器和雙絞線媒體訪問單元等。
以太網接口模塊的類型有多種，包括RJ45接口(這是以太網中最常用的一種接口，用于連接網卡)、SC光纖接口(用于通過光纖進行網絡傳輸)以及MTRJ-8針微型光纖接口(一種專門用于連接光纖與網卡之間的小型光纖接口)。
此外，IC693CMM321雙網口級聯是以太網接口模塊的一個重要優點，它支持多個I/O模塊級聯，以支持更多的I/O點。這種級聯方式可以形成可擴展的菊花鏈以太網遠程I/O陣列，提高了遠程I/O應用的可擴展性和安裝可能性，并減少了對單獨以太網交換機的需求，降低了總體成本。
總的來說，IC693CMM321以太網接口模塊在網絡通信和工業自動化領域發揮著重要作用，它通過提供標準接口和協議支持，實現了設備之間的互聯互通和數據的實時采集與傳輸。
IC693CMM321-90-30 Series Ethernet interface modules
The IC693CMM321 Ethernet interface module is a network communication device, which is usually equipped with a standard RJ45 Ethernet interface and RS232/485 serial port to ensure a compatible connection with various PLC devices. Key features of the module include real-time data acquisition, support for industry standard protocols, and seamless integration with other devices and systems.
The IC693CMM321 Ethernet interface circuit mainly consists of two parts: MAC controller and physical layer interface (PHY). Generally, 32-bit processors actually contain Ethernet MAC control inside, but do not provide physical layer interfaces, so an external physical layer chip is needed to provide Ethernet access channels. The main functions of Ethernet physical layer interface devices include physical coding subelayer, physical media accessories, twisted pair physical media subelayer, 10BASE-TX encoding/decoder and twisted pair media access unit.
There are several types of Ethernet interface modules, including the RJ45 interface (which is the most commonly used interface in Ethernet for connecting network adapters), the SC fiber interface (for network transmission over optical fibers), and the MTRJ-8-pin micro-optical fiber interface (a small optical fiber interface designed to connect optical fibers to network adapters).
In addition, the IC693CMM321 dual network port cascade is an important advantage of Ethernet interface modules, which supports the cascading of multiple I/O modules to support more I/O points. This cascading approach can form a scalable Daisy chain Ethernet remote I/O array, improving the scalability and installation possibilities of remote I/O applications, and reducing the need for a separate Ethernet switch, reducing the overall cost.
In general, the IC693CMM321 Ethernet interface module plays an important role in the field of network communication and industrial automation, which realizes the interconnection between devices and real-time data collection and transmission by providing standard interface and protocol support.
