IC697CPX935 90-30 系列 中央處理器 (CPU)
IC697CPX935是 90-30 系列中央處理器 (CPU)。該控制
器是一個單插槽 CPU 模塊，帶有三 (3)
個用于通信的串行端口。具體來說，它具有一 (1) 個 RS232 串行端口和兩 (2) 個 9 針 D-shell RS485 接口。這些端口支持 SNP
從站、無斷 SNP 從站。所有端口都支持 SNP 從站，而無中斷 SNP 從站僅適用于端口 1 和端口 2。
該IC697CPX935還配備了一個 96 MHz、80486DX4 微處理器，布爾執行速度為 0.4 微秒，它集成了 1MB 電池備份隨機存取存儲器 (RAM) 和 256 KB 非易失性閃存。該控制器可容納 12K 位的離散輸入和輸出數據。對于模擬輸入和輸出，控制器具有 8K 字內存分配。這使得控制器能夠用于大型應用，因?yàn)樗哂?I/O 容量。
IC697CPX935必須安裝在不超過 50 攝氏度的環境中。此 CPU 需要使用強制風冷風扇來保持溫度限制。冷卻風扇組件可用于此 CPU，例如額定電壓為 120 VAC (IC697ACC721) 的機架風扇組件;機架式風扇組件，工作電壓為 240 VAC (IC697ACC724);24 VDC 的機架風扇組件，目錄號為 IC697ACC744。
此 CPU 與使用 MS-DOS 或基于 Windows 的編程軟件開發的用戶程序一起下載。除了標準 I/O 和選件模塊外，該 CPU 還支持通過支持 VME C.1 的機架安裝背板與 I/O 和智能選件模塊進行通信。
GE Fanuc IC697CPX935 CPU 是 GE Fanuc 制造的單插槽 PLC CPU，是 GE Intelligent Platforms/GE Fanuc PLC 系列 90-70 產品線的一部分。該模塊帶有3個內置串口，可以對系統進行實時控制。IC697CPX935 CPU 通過安裝在背板上的機架與各種智能選件模塊進行通信，采用 VMEC.1 格式。CPU 通過軟件或使用 3 位運行和停止控制開關連接到計算機運行。它還配備了一個 96 MHz 微處理器，使該器件能夠在每 0.4 微秒后執行浮點計算。IC697CPX935 CPU 支持 12,000 個輸入和輸出以及多達 8000 個模擬輸入和輸出的任意組合。
The IC697CPX935 is a 90-30 series central processing unit (CPU). The controller is a single socket CPU module with three (3) serial ports for communication. Specifically, it has one (1) RS232 serial port and two (2) 9-pin D-shell RS485 interfaces. These ports support SNP secondary stations and uninterrupted SNP secondary stations. All ports support SNP slaves, while uninterrupted SNP slaves are only available on ports 1 and 2.
The IC697CPX935 also features a 96 MHz, 80486DX4 microprocessor with a Boolean execution speed of 0.4 microseconds, which integrates 1MB of battery backup random access memory (RAM) and 256 KB of non-volatile flash memory. The controller can accommodate 12K bits of discrete input and output data. For analog input and output, the controller has 8K word memory allocation. This allows the controller to be used for large applications because of its I/O capacity.
The IC697CPX935 must be installed in an environment that does not exceed 50 degrees Celsius. This CPU requires the use of a forced-air cooling fan to maintain temperature limits. Cooling fan assemblies are available for this CPU, such as rack fan assemblies rated at 120 VAC (IC697ACC721); Rack-mounted fan assembly, operating voltage 240 VAC (IC697ACC724); 24 VDC rack fan components. The directory number is IC697ACC744.
This CPU is downloaded with user programs developed using MS-DOS or Windows-based programming software. In addition to standard I/O and option modules, the CPU also supports communication with I/O and smart option modules via a rack-mounted backplane that supports VME C.1.
The GE Fanuc IC697CPX935 CPU is a single-socket PLC CPU manufactured by GE Fanuc as part of the GE Intelligent Platforms/GE Fanuc PLC Series 90-70 product line. The module has 3 built-in serial ports, which can control the system in real time. The IC697CPX935 CPU communicates with various intelligent option modules through a rack mounted on the backplane, in the VMEC.1 format. The CPU is connected to the computer to run either by software or using a 3-bit run and stop control switch. It is also equipped with a 96 MHz microprocessor that enables the device to perform floating-point calculations after every 0.4 microseconds. The IC697CPX935 CPU supports any combination of 12,000 inputs and outputs and up to 8,000 analog inputs and outputs.
