IC693CPU364 | 90-30 系列產品系列  | 控制器模塊

　　IC693CPU364是 90-30 系列產品系列中的控制器模塊。該控制器由 GE Fanuc 自動化制造，具有一 (1) 個以太網接口、240KB 用戶內存、80386EX 處理器，處理器速度為 25 MHz，布爾觸點的典型掃描速率為每 1K 邏輯 0.22 毫秒。

　　該控制器支持多達 2,048 個離散輸入、2,048 個離散輸出、多達 1,280 位內部離散全局存儲器、4096 個內部線圈、256 位臨時輸出線圈、可配置模擬輸入，使用 Logicmaster 軟件以 128 字為增量，從 128 字增加到 16,384 字，使用 Control 版本 2.2 從 128 字增加到 32,640 字，模擬輸出可使用 Logicmaster 編程軟件以 128 字的增量從 128 字配置到 16,384 字和 128使用 Control 版本 2.2 時，增加到 32,640 字。

　　IC693CPU364通常稱為 CPU 364。它是一個單槽寬控制器模塊，處理器類型為 80386EX，處理器速度為 25 MHz，布爾觸點的掃描速率為每 1K 邏輯 0.22 ms(典型值)。它有一個 240KB 的嵌入式用戶內存，可以根據配置的 %R、%AI 和 %AQ 變量和寄存器進行配置。它有一 (1) 個以太網通信端口，用于編程和通信。該控制器也可以通過內置的 RS485 通信端口進行通信，該端口安裝在位于底板最左側插槽的電源上。此控制器最多支持八 (8) 個基板，其中一 (1) 個基板是 CPU 基板，七 (7) 個是遠程 I/O 基板。

　　The IC693CPU364 is a controller module in the 90-30 series product family. Manufactured by GE Fanuc Automation, the controller features one (1) Ethernet interface, 240KB of user memory, an 80386EX processor with a processor speed of 25 MHz and a typical sweep rate of 0.22 ms per 1K logic for Boolean contacts.

　　The controller supports up to 2,048 discrete inputs, 2,048 discrete outputs, up to 1,280 bits of internal discrete global memory, 4096 internal coils, 256-bit temporary output coils, configurable analog inputs in 128-word increments using Logicmaster software. Increased from 128 words to 16,384 words, using Control version 2.2 increased from 128 words to 32,640 words, Analog output can be configured in 128-word increments from 128 words to 16,384 words using Logicmaster programming software and increased to 32,640 words when 128 is used with Control version 2.2.

　　IC693CPU364 is commonly referred to as CPU364. It is a single slot wide controller module with a processor type of 80386EX, a processor speed of 25 MHz, and a sweep rate of 0.22 ms per 1K logic for Boolean contacts (typical value). It has a 240KB embedded user memory that can be configured according to the configured %R, %AI, and %AQ variables and registers. It has one (1) Ethernet communication port for programming and communication. The controller can also communicate via the built-in RS485 communication port, which is installed on the power supply located in the leftmost slot of the baseboard. This controller supports up to eight (8) substrates, of which one (1) substrate is a CPU substrate and seven (7) is a remote I/O substrate.
