IS200STAIH1ABB | 印刷電路板 | 可變電阻器
產品參數:
型號：IS200STAIH1ABB
輸入電壓:24V DC
-輸入電流:1A
通道數:16
-工作溫度:-40℃~70℃℃
安裝類型:DIN導軌
產品描述
IS200STAIH1ABB是一種稱為DINrail卡的設備。這是印刷電路板或PCB的一種形式。IS200STAIH1ABB是通用電氣或GE的Mark VI系列的一個組件。Mark VI 是 Mark 系列燃氣和蒸汽工業渦輪機控制裝置中包含的幾個系列之一。
IS200STAIH1ABB是一種相對較小的印刷電路板，具有許多不同的電子元件。沿著IS200STAIH1ABB底部邊緣是一個大型綠色接線端子。該接線端子可以包含二十四 (24) 個或更多稱為端子的小金屬部件。沿著IS200STAIH1ABB的另一側是一個銀色和黑色的連接器端口。此連接器端口可用于將其他部件連接到IS200STAIH1ABB。十四 (14) 個電位器，也稱為可變電阻器，可以在IS200STAIH1ABB的不同位置找到。其中四 (4) 個電位器垂直排列在IS200STAIH1ABB的右上角。剩下的十 (10) 個電位器在IS200STAIH1ABB中心附近水平排列。位于此行上方的是另一行組件。該系列具有十 (10) 個小型晶體管。每兩 (2) 個晶體管之間是一對紅色跳線。每個跳線用于將至少兩個金屬跳線引腳連接在一起。
Product parameters:
Model: IS200STAIH1ABB
Input voltage :24V DC
- Input current :1A
Number of channels :16
- Operating temperature :-40 ° C ~70 ° C
Mounting type :DIN rail
Product description
The IS200STAIH1ABB is a device called a DINrail card. This is a form of printed circuit board or PCB. The IS200STAIH1ABB is a component of the General Electric or GE Mark VI series. The Mark VI is one of several families included in the Mark Series of gas and steam industrial turbine control units.
The IS200STAIH1ABB is a relatively small printed circuit board with many different electronic components. Along the bottom edge of the IS200STAIH1ABB is a large green terminal. The terminal may contain twenty-four (24) or more small metal parts called terminals. Along the other side of the IS200STAIH1ABB is a silver and black connector port. This connector port can be used to connect other components to the IS200STAIH1ABB. Fourteen (14) potentiometers, also known as variable resistors, can be found at various locations in the IS200STAIH1ABB. Four (4) of these potentiometers are arranged vertically in the upper right corner of the IS200STAIH1ABB. The remaining ten (10) potentiometers are arranged horizontally near the IS200STAIH1ABB center. Above this row is another row of components. The series has ten (10) small transistors. Between every two (2) transistors are a pair of red jumpers. Each jumper is used to connect at least two metal jumper pins together. The IS200STAIH1ABB contains several square black diodes
