IS220PAICH1A | 模擬I/O | 三重模塊冗余
型號：IS220PAICH1A
功能縮略語/縮寫 PAIC公司
制造者 美國通用電氣公司，GE工業系統公司
型號類型 模擬 I/O 包
無害認證 UL E207865
零件編號 IS220PAICH1A
電源 最小 27.4 VDC、標稱 28.0 VDC 和最大 28.6 VDC
IS220PAICH1A 是一款在GE Mark Vl系列下開發的模擬I/O Pack。單工和三重模塊冗余(TMR)Mark V 控制系統可用于小型應用和大型集成系統，控制范圍從單個模塊到多個分布式模塊。該系統的吞吐量允許在 40 毫秒內操作多達 9個 21 插槽 VME 機架的 I/0 板，包括數據投票。在一種稱為軟件實現容錯的方法中，輸入在軟件中進行投票(SIFT)。每個控制模塊的 VCMI 板通過其自己的 IONet 從控制模塊背板和其他模塊獲取輸入。
除了通用 I/0 之外，Mark V 還擁有許多專為與特定傳感器和執行器直接通信而設計的板。在許多情況下，這可以最大限度地減少或消除大量的插入儀器。因此，消除了最關鍵區域中許多可能的單點故障，從而提高了運行可靠性并降低了長期維護成本。由于與傳感器和執行器的直接連接，診斷還可以直接詢問設備上的裝置，以獲得最佳效果。此信息用于評估設備和系統的性能。外圍儀表的消除減少了備件庫存，這是這種設計的一個微妙的好處。
Model: IS220PAICH1A
Functional acronyms/abbreviations PAIC Corporation
Manufactured by General Electric, GE Industrial Systems
Model Type Analog I/O packet
Harmless Certification UL E207865
Part number IS220PAICH1A
The minimum power supply is 27.4 VDC, nominal 28.0 VDC, and maximum 28.6 VDC
The IS220PAICH1A is an analog I/O Pack developed under the GE Mark Vl series. Simplex and Triple Module Redundancy (TMR)Mark V control systems can be used in small applications and large integrated systems, with control ranging from a single module to multiple distributed modules. The system's throughput allows the operation of up to nine I/0 boards of a 21-slot VME rack in 40 milliseconds, including data voting. In an approach called software Implementation Fault tolerance, input votes in software (SIFT). Each control module's VCMI board receives input from the control module backplane and other modules through its own IONet.
In addition to the universal I/0, the Mark V has a number of boards designed for direct communication with specific sensors and actuators. In many cases, this minimizes or eliminates a large number of inserted instruments. As a result, many possible single points of failure in the most critical areas are eliminated, improving operational reliability and reducing long-term maintenance costs. Thanks to the direct connection to the sensors and actuators, diagnostics can also be directly queried on the device for optimal results. This information is used to evaluate the performance of devices and systems. The elimination of peripheral meters reduces spare parts inventory, which is a subtle benefit of this design
