IS220PAICH2A  |   模擬 I/O 包  |   TMR系統有一個單獨的控制模

型號 ：IS220PAICH1A

輸入電壓范圍:12-48VDC

輸出電壓范圍:5VDC。

輸出電流:最大10A。

效率:大于90%。

尺寸:170mm x105mmx32mm.

重量:約120g。

運行溫度:-20°C至+50°C。

存儲溫度:-40°C至+70°C。

環境濕度:5%至95%相對濕度(無凝露)

產品描述

該型號被描述為模擬 I/O 包，IS220PAICH1A 型號已被批準用于危險和非危險場所。在模型的正面，有四個指示器。底部還有一個端口，被描述為 I/O 端口。PAIC電池組可以使用多種電壓，PAIC電池組的最小電壓為27點4伏直流電。

由于 IS220PAICH1A 包能夠在許多地點使用，因此有多種與 包相關的認證，其中一些是危險場所、一類二區 IIC 組、一類二區 A、B、C、D 和 ATEX 二區、IIC 組和非危險場所。以下認證用于地點、UL E207685 和 UL DEMKO 12 ATEX 1114875X，請注意 UL E207685 認證在許多地點使用。

有三種型號可以與IS220PAICH1A單元一起使用，分別是IS200STAIH1A和IS200STAIH2A以及IS20TBAIH1C型號。所有這些型號都被稱為輸入輸出端子板。

PAIC I/O 包的典型位置將位于兩個可用的 VME 機架之一中，即 13 個或 21 個插槽機架。 請注意，該裝置通常與三重模塊化冗余架構系統一起使用

。TMR系統有一個單獨的控制模塊、I/O網絡和主處理器卡。

Model: IS220PAICH1A

Input voltage range :12-48VDC

Output voltage range :5VDC.

Output current: Max. 10A.

Efficiency: greater than 90%.

Size :170mm x105mmx32mm.

Weight: About 120g.

Operating temperature :-20°C to +50°C.

Storage temperature :-40°C to +70°C.

Ambient humidity :5% to 95% relative humidity (no condensation)

Product description

The model is described as an analog I/O package, and the IS220PAICH1A model has been approved for use in hazardous and non-hazardous locations. On the front of the model, there are four indicators. There is also a port on the bottom, which is described as an I/O port. The PAIC battery pack can use a variety of voltages, the minimum voltage of the PAIC battery pack is 27.4 volts DC.

Because the IS220PAICH1A package can be used in many locations, there are several certifications related to the package, some of which are hazardous Sites, Zone I II IIC Group, Zone I II A, B, C, D and ATEX Zone II, IIC Group and non-hazardous sites. The following certifications are for locations, UL E207685, and UL DEMKO 12 ATEX 1114875X, please note that the UL E207685 certification is used in many locations.

There are three models that can be used with the IS220PAICH1A unit, the IS200STAIH1A and IS200STAIH2A, and the IS20TBAIH1C model. All of these models are referred to as input/output terminals.

The typical location for a PAIC I/O package will be in one of the two available VME racks, i.e. 13 or 21 slot racks. Note that this device is often used with triple modular redundant architecture systems. The TMR system has a separate control module, I/O network, and main processor card.
