IS200TREGH1BDC  |  用于燃?xì)廨啓C的緊急跳閘端子板 |  I/O數據包

　　IS200TREGH1BDC是通用電氣公司生產的用于燃?xì)廨啓C的緊急跳閘端子板

　　Ve系列機床控制系統。它由母線和發電機電壓輸入的兩個電壓交換組成

　　傳感器(PTS)和I/O數據包的條件速度信號輸入。此外，它還有12個

　　繼電器，每個頂部都有一根銀線。接力棒是黑白相間的

　　連續六次。兩行。端子板還具有DC-37引腳連接器，可與端子板連接

　　作為后備跳閘繼電器的電纜。

　　在Mark Vle或Mark VleS控制系統中，備份保護由SPRO和PPRO/YPRO提供

　　通過連接到繼電器板形成的。PTUR或YTUR, TTUR和主跳閘繼電器端子板

　　提供主要保護，安裝時，它安裝在DIN導軌上的金屬板載體上，也可以攜帶

　　它安裝在用螺栓固定在面板上的金屬板組件上。

　　IS200TREGH1BDC輸入輸出配置

　　IS200TREGH1BDC端子板具有全面的輸入輸出范圍，確保高效的操作和控制:

　　客戶輸入終端:這些輸入由兩個24點可插拔的屏障終端提供便利，為客戶特定的輸入提供有組織和可訪問的接口

　　. 9個無源脈沖速率裝置:這些裝置分布在X//Z段，每段3個，具有負儀表感應齒輪，從而能夠精確測量渦輪轉速。

　　信號撲動跳線模塊:IS200TREGH1BDC跳線模塊在使一組三速輸入撲動到所有三個PPRO VO封裝中發揮關鍵作用，優化信號分配以實現統一的功能。

　　125 VDCTMR投票淘汰接觸;這些輸出觸點標記為H2A和H4A，是系統跳閘激活的關鍵部件，確保在緊急情況下采取故障安全措施。

　　電壓檢測電路:從24到125 VDC的四個電路專門用于監測脫扣串，通過連續監測電壓水平來提高系統的安全性和可靠性。

　　子板連接器:包含子板連接器允許可選的功能擴展，為附加或增強的功能提供可擴展性和自定義可能性。

　　The IS200TREGH1BDC is an emergency trip terminal board manufactured by General Electric for use in gas turbines

　　Ve series of machine control system. It consists of two voltage interchanges for bus and generator voltage inputs

　　Sensors (PTS), and conditional speed signal inputs for I/O packets. In addition, it also has twelve

　　Relays, each with a silver wire at the top. Relays are white and black, each

　　Six in a row. Two rows. The terminal board also has a DC-37 pin connector that can be connected to the terminal board

　　Cable to serve as backup trip relay.

　　In Mark Vle or Mark VleS control systems, backup protection is provided by SPRO and PPRO/YPRO

　　Formed by wiring to a relay board. PTUR or YTUR, TTUR and main trip relay terminal board

　　Provides the main protection, when installed, it is mounted on the DIN rail on a metal plate carrier, can also be carried

　　It is mounted on a metal plate assembly bolted to the panel.

　　IS200TREGH1BDC Input and output configuration

　　The IS200TREGH1BDC terminal board has a comprehensive input and output range to ensure efficient operation and control:

　　Customer input terminals: These inputs are facilitated by two 24-point pluggable barrier terminals, providing an organized and accessible interface for customer-specific inputs

　　. Nine passive pulse rate devices: These devices are distributed in the X//Z section, three in each section, with negative meter induction gears, thus enabling accurate measurement of turbine speed.

　　Jumper blocks for signal flapping: The IS200TREGH1BDC jumper blocks play a key role in enabling a set of three-speed inputs to flap to all three PPRO VO packages, optimizing signal distribution for uniform functionality.

　　125 VDCTMR voting out contact; These output contacts, labeled H2A and H4A, are critical components for system trip activation, ensuring fail-safe measures in case of emergency.

　　Voltage Detection circuits: Four circuits from 24 to 125 VDC are dedicated to monitoring trip strings to improve system safety and reliability by continuously monitoring voltage levels.

　　Child board connectors: The inclusion of child board connectors allows for optional feature extensions, providing scalability and customization possibilities for additional or enhanced features.
