IS200TTURH1CCC  |  渦輪終端板  |   用于連接TRPG板

　　模型:IS200TTURH1CCC

　　規格:

　　供電電壓:24VDC

　　功耗:<20瓦

　　通訊協議:Modbus, Profibus，

　　EthernetlP

　　數據傳輸速率:最高可達10mbps

　　額定工作溫度范圍:-40℃~ +70℃

　　防護等級:IP67

　　IS200TTURH1CCC馬克渦系統的大渦

　　車輪終端板(TTUR)

　　該是200轉h1 CCC是一個更大的渦輪終端板(TTUR)為馬克維爾系統。Ge不再支持markle系列部件，現在可能很難找到。AX Control確實試圖將200轉的h1CCC作為翻新或新的剩余產品呈現

　　剩余的組件保存在庫存和IS200TTURH1CCC通常連接到主渦輪保護PCB(VTUR)。TTU

　　R PTUR組件，用于控制TRPG(Main Trip Terminal)板。它支持單工和TMR應用程序。

　　在IS200TTURH1CCC上，有三個37針母端口和三個37針公連接器。連接器用于連接TRPG板。有兩個端子板，有兩排端子。第一端子排具有標記為1-24的端子。第二端行有標記為25-48的端子。有兩個綠色的3針插孔和一個白色的4針插孔。在底角處，有兩個加強的端子孔。

　　Model: IS200TTURH1CCC

　　Specifications:

　　Power supply voltage :24VDC

　　Power consumption :<20 watts

　　Communication protocol :Modbus, Profibus,

　　EthernetlP

　　Data transfer rate: up to 10 Mbps

　　Rated temperature range :-40°C to +70°C

　　Protection level :IP67

　　IS200TTURH1CCC Arger vortex of Mark Vle system

　　Wheel Terminal Board (TTUR)

　　The is 200 tur h1 CCC is an Arger Turbine terminal board (TTUR) for Mark Vle systems. Ge no longer supports MarkVle series parts, which may now be hard to find. AX Control did attempt to present the is 200 tur h1CCC as a refurbished or new leftover

　　The remaining components are kept in stock and the IS200TTURH1CCC is usually connected to the main turbine Protection PCB(VTUR). TTU

　　R Uses the PTUR component to control the TRPG(Main Trip Terminal) board. It supports simplex and TMR applications.

　　On the IS200TTURH1CCC, there are three female 37-pin ports and three male 37-pin connectors. Connectors Connect the TRPG board. There are two terminal boards with two rows of ends. The first terminal block has terminals labeled 1-24. The second end row has terminals labeled 25-48. There are two green 3-pin jacks and one white 4-pin jacks. At the bottom corner, it has two reinforced terminal holes.
