IC670MDL740J| IC670MDL740 | 分立式輸出模塊
產品型號： IC670MDL740J
產品類型：分立式輸出模塊
成色：全新/非全新
質保：一年
可用性：現貨
從電源汲取的電流： 111毫安
輸出分組：單組
最大負載電流 ：0.5 安培，10-30 伏直流電
輸出響應時間： 0.5 A 阻性負載時為 200 ms
輸出壓降： 最大 0.5 伏
保護 內置保險絲，用于群體保護;
輸出壓降 ：最大 0.5 伏
輸出漏電流： 30 VDC 時為 0.5 mA
該IC670MDL740J是由GE Fanuc制造的正邏輯分立輸出模塊。該模塊是一個通用輸出模塊，安裝在總線接口單元 （BIU） 上，用于實現擴展 I/O 解決方案。它通常用于為指示燈、繼電器線圈、電磁閥驅動設備和類似額定電流的輸出設備通電，因?yàn)镮C670MDL740在電壓輸出范圍為 10-30 VDC 和 24 VDC 的標稱電壓下，每通道提供 0.5 安培的輸出電流和每個模塊總共 4 安培的輸出電流。
該IC670MDL740J設計有單獨的狀態 LED 指示燈，指示模塊每個輸出通道的開/關狀態。整個 I/O 組都安裝了一個公共保險絲，該保險絲還分配了一個 LED 指示燈，用于描述保險絲熔斷狀態。該模塊產生的浪涌電流額定值為 2 安培，最大持續時間為 100 ms。輸出通道最小負載電流為每點 1 mA，輸出壓降為 0.5 V，輸出漏電流為 0.5 mA（30 VDC），開和關信號轉換的典型響應時間。
IC670MDL740J| IC670MDL740 | Separate output module
Product model: IC670MDL740J
Product type: Separate output module
Finish: New/not new
Warranty: One year
Availability: In stock
Current drawn from the power supply: 111 mA
Output group: single group
Maximum load current: 0.5 amps, 10-30 volts DC
Output response time: 200 ms under 0.5A resistive load
Output voltage drop: 0.5 V Max
Protection built-in fuse for group protection;
Output voltage drop: 0.5 V Max
Output leakage current: 0.5 mA at 30 VDC
The IC670MDL740J is a positive logic discrete output module manufactured by GE Fanuc. This module is a universal output module that is installed on the Bus Interface Unit (BIU) to implement an extended I/O solution. It is commonly used to energize indicator lights, relay coils, solenoid drive devices, and output devices with similar current ratings, because the IC670MDL740 operates at nominal voltages in the voltage output range of 10-30 VDC and 24 VDC. Each channel provides 0.5 amps of output current and a total of 4 amps of output current per module.
The IC670MDL740J is designed with a separate status LED indicator indicating the on/off status of each output channel of the module. A common fuse is installed throughout the I/O group, which is also assigned an LED indicator to describe the blown fuse status. The module generates an inrush current rated at 2 amps with a maximum duration of 100 ms. The minimum load current of the output channel is 1 mA per point, the output voltage drop is 0.5 V, the output leakage current is 0.5 mA (30 VDC), and the typical response time of the on and off signal conversion.
