>>>>>型號:IS200TTURH1CFD 終端板 具有多個表面貼裝繼電器

【功能描述】

IS200TTURH1C是通用電氣的終端板。該板旨在與該公司后來的Speedtronic系統兼容。這包括Mark VI和Mark VIe系統這兩個系統以及早期Speedtronic系統的組件保留了現成的、隨時可以發貨的庫存。自1960年代后期最早的迭代（Mark I）可用于工業燃?xì)廨啓C(jī)和蒸汽輪機管理以來，Speedtronic系統逐漸變得更加復雜。

IS200TTURH1C主要是矩形的，有一些小切口。該板與其他PCB（如PTUR和VTUR板）一起使用，以控制發電機的同步。這主要是通過硬件和連接來完成的。

該IS200TTURH1C具有多個表面貼裝繼電器。此外，該板使用可變電阻器，并且在板中心附近還有兩個變壓器。與其他電路板組件的通信通過d-shell連接器（公頭和母頭）、插頭連接器和接線端子進行。電路板上最大的兩個接線端子具有螺釘安裝連接器，這些連接器已編號以供參考。

>>>>>型號:IS200TTURH1CFD 終端板 具有多個表面貼裝繼電器

【英文介紹】

The IS200TTURH1C is a General Electric terminal board. The board was designed to be compatible with the company's later Speedtronic system. This includes the Mark VI and Mark VIe systems. AX Control maintains a ready-made, ready-to-ship inventory of components for both systems, as well as earlier Speedtronic systems. Since the earliest iterations (Mark I) became available for industrial gas turbine and steam turbine management in the late 1960s, Speedtronic systems have gradually become more complex.

The IS200TTURH1C is mostly rectangular with a few small cuts. The board is used in conjunction with other PCBS, such as PTUR and VTUR boards, to control the synchronization of the generator. This is mostly done through hardware and connectivity.

The IS200TTURH1C has multiple surface mount relays. In addition, the board uses variable resistors, and there are two transformers near the center of the board. Communication with other board components occurs through d-shell connectors (male and female), plug connectors, and terminal blocks. The two largest terminals on the board have screw mount connectors, which are numbered for reference.
