>>>>>型號:DS200DMCBG1AED 處理器板 采用AMD處理器
【功能描述】
DS200DMCBG1AED處理器主板是一款通用的電腦主板，采用AMD處理器，具有較高的性能和穩定性。
該主板采用Socket FM2+接口，支持AMD A8、A10、A12系列處理器，擁有2個DDR3內存插槽、4個SATA 3.0接口、1個PCI-E 3.0 x16插槽、1個PCI-E 2.0 x16插槽等配置。
此外，該主板還支持雙通道內存技術，可提供高速的數據傳輸速度，適合于需要高性能計算和多任務處理的用戶。
GE DOS DUP處理器板DS200DMCBG1AED包含三個26針連接器、一個40針連接器和19個跳線。該板還具有2個LED。GE DOS DUP處理器板DS200DMCBG1AED還裝有兩個保險絲，可提供過壓保護。如果電路板的電源發生瞬時浪涌，保險絲中的元件熔斷，電路板完全停止工作，或在保險絲保護的電路中停止工作。如果保險絲的額定值錯誤，電路板上的組件會損壞。因此，如果更換保險絲，請僅使用相同額定值的更換件。有關保險絲的信息在出廠時隨附的原始電路板的信息中提供?；蛘撸赡軙l(fā)現保險絲上印有額定值。
檢查保險絲的狀況是對電路板進行故障排除的快速初始步驟，因為它只需要目視檢查。如果您懷疑電路板的性能未達到預期，您可以打開電路板機柜門并找到電路板上的保險絲。如果一個或兩個保險絲熔斷，請斷開驅動器的所有電源，卸下電路板，然后更換保險絲。重新啟動驅動器并確定主板是否恢復正常運行。如果問題仍然存在，下一步是查看電路板上的2個LED。LED在板上標識為CR2和CR12，亮起時為紅色。
>>>>>型號:DS200DMCBG1AED 處理器板 采用AMD處理器
【英文介紹】
DS200CTBAG1ADD GE Mark V terminal board
DS200CTBAG1ADD is a terminal board designed for GE Mark V Speedtronic systems. The Speedtronic family was created by General Electric to control large and small gas and steam turbine systems. MKV can be designed with simplex or TMR/ triple modular redundancy architecture to meet the needs of interconnected turbine systems. The boards are no longer manufactured and distributed by GE, but can be purchased as fully tested and refurbished models through AX Control.
The DS200CTBAG1ADD is a long, narrow circuit board with only a few types of components. It drilled holes in each corner and long side to allow for the installation of hardware and other connections. Two of the holes are surrounded by conductive material. The board is marked with an identification code, including the board ID number and the company logo.
DS200CTBAG1ADD is an analog terminal module. It is usually located in the R5> Inside the kernel. The board has multiple connectors, including two COREBUS connectors (JAI and JAJ). The DS200CTBAG1ADD has two double-stacked terminal blocks located at the edge of a longboard with multiple connectors on each terminal block. There are 5 vertical pin cable connectors, 2 vertical pin connector connectors, and a 9-pin male serial connector.
Other components on the DS200CTBAG1ADD include a resistor network array, relays, transistors, more than two dozen metal oxide varistors (MOV), a dozen jumper switches, and many capacitors and resistors. For more information, see GE's original technical support offering.
