IS200AEADH1A  |  輸入/輸出網格叉模塊 |  IS210AEAAH2B

　　型號：IS200AEADH1A

　　功能描述： 輸入/輸出網格叉模塊

　　產品描述

　　該IS200AEADH1A是GE制造的輸入/輸出網格叉板，作為其Mark VIe Speedtronic系統的一部分，用于管理風力渦輪機系統控制。該系統還設計用于BOP(工廠平衡)控制。雖然該電路板不再由OEM生產，但仍可以通過AX Control作為新的剩余產品或翻新的二手庫存購買。用戶可以通過原始設備制造商最初購買時提供的出版物(包括各種手冊和用戶指南)找到有關IS200AEADH1A的其他重要信息，盡管有關該產品的基于網絡的材料很少。這些材料將包括重要的處理和安裝信息，在打開電路板之前應閱讀這些信息。

　　硬件提示和規格

　　IS200AEADH1A是一個矩形電路板，沒有連接的前面板。Mark VIe Speedtronic 機架系統通常具有 13 或 21 插槽 VME 排列。與許多通用電氣制造的 PCB 型號一樣，PCB 角上的工廠制造鉆孔允許多種安裝選項。 這是GE板的高度可連接版本;因?yàn)樗哂腥齻€(gè)垂直引腳端子排，每個排有12個引腳。這些端子排以平行排列方式放置在電路板上，以實現理想的配置目的。該板的連接類型多種多樣，并具有多種其他類型的 PCB 連接器，包括：

　　刺入式連接器

　　插頭連接器

　　直角連接器

　　前面提到的直角連接器延伸到印刷電路板的整個右邊緣。

　　電路板上的其他電路板組件包括兩個散熱器組件和八個繼電器，它們位于一組中。IS200AEADH1A PCB擁有繞線電阻器和其他材料制成的電阻器，以及一系列電容器和集成電路。

　　雖然IS200AEADH1A在線信息相對有限，但考慮到其作為傳統系列產品的地位;該AEAD模塊具有大量信息，可以通過仔細分析其個性化產品編號來揭示。 IS200AEADH1A的“IS200”部分將其指定為通用電氣在美國制造的正常組裝PCB。

　　Model: IS200AEADH1A

　　Function Description: Input/output grid fork module

　　Product description

　　The IS200AEADH1A is an input/output grid forkboard manufactured by GE as part of its Mark VIe Speedtronic system for managing wind turbine system controls. The system is also designed for BOP (Plant Balance) control. While the board is no longer manufactured by Oems, it can still be purchased as a new surplus or refurbished used stock through AX Control. Users can find other important information about the IS200AEADH1A through the publications provided by the original equipment manufacturer at the time of initial purchase, including various manuals and user guides, although web-based materials about the product are scarce. These materials will include important handling and installation information, which should be read before opening the board.

　　Hardware tips and specifications

　　The IS200AEADH1A is a rectangular circuit board with no attached front panel. Mark VIe Speedtronic rack systems typically feature 13 or 21 slot VME arrangements. As with many GE manufactured PCB models, factory-made holes in the PCB corners allow for a variety of mounting options. This is the highly connectable version of the GE board; Because it has three vertical pin terminal rows, each row has 12 pins. These terminals are placed on the board in a parallel arrangement to achieve the desired configuration purpose. The board has a wide variety of connection types and features a variety of other types of PCB connectors, including:

　　Prick type connector

　　Plug connector

　　Right Angle connector

　　The aforementioned right Angle connector extends to the entire right edge of the printed circuit board.

　　Other board components on the board include two radiator assemblies and eight relays, which are located in a group. The IS200AEADH1A PCB has wire-wound resistors and resistors made of other materials, as well as a range of capacitors and integrated circuits.

　　Although IS200AEADH1A online information is relatively limited, but considering its status as a traditional series of products; This AEAD module has a large amount of information that can be revealed by careful analysis of its personalized product number. The "IS200" section of the IS200AEADH1A designates it as a normally assembled PCB manufactured by General Electric in the United States.
