COOPER TURBOCOMPRESSOR PN：P3798102-00010 VANTAGE 用戶界面模塊和 DISLPLAY。

Vantage 控制面板

兩個主要組件是 P3798102-00010 用戶界面模塊 （UIM） 和 P3798102-00010 主邏輯模塊 （MLM）。這兩個模塊都是獨立的。

P3798102-00010 UIM 是一款全頁背光液晶 LCD 顯示器，帶有集成的 15 鍵觸覺鍵盤。顯示屏提供有關壓縮機運行條件和設置的詳細信息。

面板中包含一個或多個 P3798102-00010 MLM 主邏輯模塊。每個 MLM 都包含一個電源、一個微處理器和 I/O（輸入/輸出）通道。對于需要增加 I/O 容量的應用，額外的從 MLM 可以隨附在單個控制包中的主 MLM。

COOPER TURBOCOMPRESSOR PN: P37988102-00010 VANTAGE User Interface Module and DISLPLAY.

Vantage Control Panel

The two main components are the P37988102-00010 User Interface Module (UIM) and the P37988102-00010 Main Logic Module (MLM). Both modules are independent.

The P37988102-00010 UIM is a full-page backlit LCD display with an integrated 15-key haptic keyboard. The display provides detailed information about compressor operating conditions and Settings.

The panel contains one or more P3798102-00010 MLM main logic modules. Each MLM contains a power supply, a microprocessor, and I/O (input/output) channels. For applications that require increased I/O capacity, additional slave MLM can be included with the master MLM in a single control package.
