T9402 產品介紹概述
T9402 是由 ICS Triplex 公司生產的高性能、高可靠性的工業控制處理器模塊，屬于 Trusted TMR 系統。該模塊采用先進的處理器技術和冗余設計，為工業控制系統提供卓越的性能和可靠性。
產品特點
- 高性能：采用多核處理器，處理能力強大，可同時處理多個任務。
- 高可靠性：三冗余設計，故障率極低。
- 可擴展性：支持多種 I/O 模塊，可靈活配置。
- 實時性：具有極高的實時性，適用于對響應時間要求苛刻的應用。
- 安全性：內置安全機制，保護系統免受攻擊。
產品參數
- 輸入電壓：24V DC。
- 工作溫度范圍：-40℃至+70℃。
- 通信接口：支持以太網、Modbus、RS232/485 等。
- 尺寸：110mm x 180mm x 45mm。
- 重量：0.5 kg。
- 輸入通道：16個數字輸入。
- 輸出通道：16個數字輸出。
- 模擬輸入/輸出：支持模擬信號的輸入和輸出。
- 處理能力：采用32位RISC CPU，處理速度快。
產品作用與用途
T9402 的主要作用是作為工業控制系統的核心，提供高性能、高可靠性的控制功能。它廣泛應用于以下領域：
- 過程控制：石油化工、電力等行業的過程控制系統。
- 安全關鍵系統：航空航天、核電等對安全要求極高的系統。
- 運輸系統：鐵路信號、地鐵控制等。
- 智能制造：工業自動化、機器人控制等。
應用領域示例
- 工業控制面板：T9402 作為控制系統的核心，負責接收來自傳感器的數據，并向執行器發出控制指令。
- 機器人控制：T9402 控制機器人的運動，實現自動化生產。
總結
T9402 Product introduction Overview
The T9402 is a high-performance, highly reliable industrial control processor module manufactured by ICS Triplex for the Trusted TMR system. The module uses advanced processor technology and redundant design to provide superior performance and reliability for industrial control systems.
Product characteristics
High performance: Multi-core processor, powerful processing power, can handle multiple tasks at the same time.
High reliability: Triple redundancy design, very low failure rate.
Scalability: Support a variety of I/O modules, flexible configuration.
Real-time: Extremely real-time, suitable for applications with demanding response times.
Security: Built-in security mechanism to protect the system from attacks.
Product parameter
Input voltage: 24V DC.
Operating temperature range: -40℃ to +70℃.
Communication interface: Support Ethernet, Modbus, RS232/485, etc.
Dimensions: 110mm x 180mm x 45mm.
Weight: 0.5kg.
Input channel: 16 digits input.
Output channel: 16 digital outputs.
Analog input/output: Supports the input and output of analog signals.
Processing power: 32-bit RISC CPU, fast processing speed.
Product function and use
The main role of the T9402 is to serve as the core of industrial control systems, providing high-performance, highly reliable control functions. It is widely used in the following areas:
Process control: Process control system for petrochemical, electric power and other industries.
Safety critical systems: aerospace, nuclear power and other systems with high safety requirements.
Transportation system: railway signal, subway control, etc.
Intelligent manufacturing: industrial automation, robot control, etc.
Application field example
Industrial control panel: As the core of the control system, the T9402 is responsible for receiving data from the sensor and issuing control instructions to the actuator.
Robot control: The T9402 controls the movement of the robot for automated production.
Sum up
The T9402 is a powerful and reliable industrial control processor for applications that require high system performance and reliability. Its multi-core processor, triple-redundancy design and rich interface make it the first choice for many industrial control systems.
