【功能描述】

GE I/O 控制板DS200SIOBH1ABA具有 20 個跳線和 3 個開關塊，每個塊中有 6 個開關，總共 18 個開關。它還裝有 1 個 LED 和一個 40 針連接器。 GE I/O 控制板上的跳線DS200SIOBH1ABA原始板上的跳線都設置為出廠默認值。在安裝電路板之前，您可以查看印刷材料中的信息，以了解跳線的備用設置以及它們?nèi)绾胃淖冸娐钒宓牟僮?。有些跳線只有一個支撐位置，因此無法更改。

當您發現必須更換電路板時，最佳做法是將跳線設置在新電路板中，以匹配舊電路板上的跳線位置。這樣，電路板將執行相同的操作并支持驅動器性能。首先卸下將舊板固定在板架中的螺釘，然后用兩只手從驅動器上卸下板。小心防止主板撞擊驅動器中的其他組件。在附近找一個干凈干燥的表面，把一個防靜電袋壓平。將舊板放在袋子上。打開裝有更換板的密封保護袋，然后滑出板。用兩只手拿著它，把它放在舊板旁邊。設置開關以匹配舊板上的開關位置。

 >>>>>型號:DS200SIOBH1ABA GE I/O控制板 設置在新電路板中

【英文介紹】

The GE I/O control board DS200SIOBH1ABA has 20 jumpers and 3 switch blocks with 6 switches in each block for a total of 18 switches. It is also equipped with 1 LED and a 40-pin connector. Jumpers on the GE I/O control board DS200SIOBH1ABA Jumpers on the original board are set to factory defaults. Before installing the board, you can look at the information in the printed material to understand the alternate Settings of the jumpers and how they change the operation of the board. Some jumpers have only one support position and therefore cannot be changed.

When you find that you must replace the board, the best practice is to set the jumper in the new board to match the jumper position on the old board. This way, the board will perform the same operation and support driver performance. First remove the screws holding the old board to the board frame, then remove the board from the drive with two hands. Be careful to prevent the motherboard from hitting other components in the drive. Find a clean, dry surface nearby and flatten an anti-static bag. Place the old board on the bag. Open the sealed protective bag containing the replacement plate and slide out of the plate. Hold it in both hands and place it next to the old board. Set the switch to match the switch position on the old board.
