IS220PTURH1A | Mark VI系統組件 | 渦輪機控制終端板
零件編號：IS220PTURH1A
產品類型: PTUR 渦輪機專用主跳閘模塊
產品描述
IS220PTURH1A是GE為其Mark VI系統創建的組件。Mark VI 是 GE 發布的用于燃氣/蒸汽輪機管理的最終 Speedtronic 系統之一。
IS220PTURH1A是主渦輪機專用主跳閘包。 該組件在渦輪機控制終端板和一個或兩個以太網網絡之間提供電氣接口。該電池組的輸出通過連接到相關端子板的 DC-62 引腳連接器進行。
IS220PTURH1A采用黑色外殼制成，帶有空氣流通開口。該外殼的正面有多個 LED 指示燈，以及一個 IR(紅外端口)。此包中未使用此端口。在這個外殼內，有一個處理器板、一個專門用于渦輪機控制的第二塊板和一個模擬采集輔助板。電池組安裝在TTURH1C端子板上。該處理器板具有兩個 10/100 以太網端口、閃存和 RAM、一個用于識別的只讀芯片、一個內部溫度傳感器和一個復位電路。
該IS220PTURH1A允許自動重新配置，這將自動從控制器下載到 I/O 包。重新配置包括基本負載、引導負載、固件和參數。必須啟用自動重新配置才能執行此操作。在 Toolbox ST 應用程序中，通過組件編輯器啟用或禁用此功能。
Part number: IS220PTURH1A
Product Type: PTUR turbine special main trip module
Product description
The IS220PTURH1A is a component created by GE for its Mark VI system. The Mark VI is one of the final Speedtronic systems released by GE for gas/steam turbine management.
IS220PTURH1A is a special main trip package for the main turbine. This component provides an electrical interface between the turbine control terminal board and one or two Ethernet networks. The output of this battery pack is performed via a DC-62 pin connector connected to the relevant terminal board.
The IS220PTURH1A is made of black housing with an air outlet. The front of the housing has multiple LED indicators, as well as an IR (infrared port). This port is not used in this package. Inside this enclosure, there is a processor board, a second board dedicated to turbine control, and an analog acquisition auxiliary board. The battery string is installed on the TTURH1C terminal board. The processor board features two 10/100 Ethernet ports, flash memory and RAM, a read-only chip for identification, an internal temperature sensor and a reset circuit.
The IS220PTURH1A allows automatic reconfiguration, which will automatically download from the controller to the I/O package. Reconfiguration includes base load, boot load, firmware, and parameters. You must enable automatic reconfiguration to perform this operation. Enable or disable this feature in the Toolbox ST application through the component editor.
