IS200TREAH2ACC | 緊急跳閘端子板 | 確保高效的操作和控制
部件號:IS200TREAH2ACC
制造商:通用電氣
產地:美國(USA)
尺寸:33.02厘米高x 10.16厘米寬
額定溫度:30 ~ 65℃
產品類型:應急跳閘端子板
可用性:有現貨
系列:Mark VIe
功能描述
IS200TREAH2ACC是GE公司開發的緊急跳閘端子板。它是Mark VIe控制系統的一部分。TREAH1A端子板是Mark* VIe系統的一個組成部分，專為與PPRO渦輪機I/O集無縫集成而設計。該板的輸入和輸出滿足各種功能是至關重要的渦輪運行和安全。
輸入輸出配置
端子板具有全面的輸入輸出范圍，確保高效的操作和控制;
客戶輸入終端:IS200TREAH2ACC這些輸入由兩個24點可插拔的屏障終端提供便利，為客戶特定的輸入提供有組織和可訪問的接口。
九個無源脈沖速率裝置:這些裝置分布在X/Y/Z部分，每個部分三個，負責感應齒輪，從而能夠精確測量渦輪轉速。
用于信號震蕩的跳線模塊:跳線模塊在使一組三速輸入能夠震蕩到所有三個PPRO I/O數據包，優化信號分配以實現統一功能方面發揮關鍵作用。
125 V DC TMR投票輸出觸點:這些標有H2A和H4A的輸出觸點是系統跳閘激活的關鍵部件，確保在緊急情況下采取故障安全措施。
電壓檢測電路:從24到125 V DC的四個電路專門用于監測脫扣串，通過連續監測電壓水平來提高系統的安全性和可靠性。
子板連接器:IS200TREAH2ACC包括允許可選功能擴展的子板連接器，為附加或增強功能提供可擴展性和定制可能性。
TMR系統信號分配
在TMR (Triple modular redundancy)系統中，信號通過JX1、JY1和JZ1 DC-62 PPRO連接器進行分發，保證了多個組件的冗余和功能一致，從而提高了系統的可靠性和安全性
安裝
接線配置:IS200TREAH2ACC電壓檢測和斷路器繼電器接線:將電壓檢測電路和必要的斷路器繼電器連接小心地連接到指定的I/O端子TB1上。這種設置有助于可靠有效地處理電壓監測和系統跳閘激活。
被動脈沖速率拾取器:被動脈沖速率拾取器連接到TB2，在感應齒輪和精確測量渦輪轉速方面發揮關鍵作用。
端子及規格:I/O端子:每個端子(TB1和TB2)均用2顆螺釘固定，保證接線穩定。這些模塊設計有24個端子，能夠接受高達#12 AWG的電線，實現堅固高效的電線連接。
屏蔽端帶:屏蔽端帶與各端子相鄰，與機箱接地可靠連接，為設備提供額外的保護，防止?jié)撛诟蓴_，保證信號完整性和系統可靠性。
這種精心的布線配置，將特定組件連接到指定的端子，以及屏蔽的端帶，確保了配線板的安全有序安裝。這種謹慎的安裝程序?qū)τ跍u輪系統內的最佳功能和性能至關重要。
specification
Part number: IS200TREAH2ACC
Manufacturer: General Electric
Country of Production: USA (USA)
Dimensions: 33.02 cm high x 10.16 cm wide
Rated temperature: 30 to 65 oC
Product Type: Emergency trip terminal board
Availability: In stock
Series: Mark VIe
Function description
The IS200TREAH2ACC is an emergency trip terminal board developed by GE. It is part of the Mark VIe control system. The TREAH1A terminal board is an integral component of the Mark* VIe system and is specifically designed for seamless integration with the PPRO Turbine I/O set. The board’s inputs and outputs satisfy a variety of functions that are critical to turbine operation and safety.
Input and output configuration
The terminal board has a comprehensive input and output range to ensure efficient operation and control:
Customer input terminals: IS200TREAH2ACC These inputs are facilitated by two 24-point pluggable barrier terminals, providing an organized and accessible interface to customer-specific inputs.
Nine passive pulse rate devices: These devices are distributed in the X/Y/Z section, three in each section, and are responsible for sensing the gears, thus enabling accurate measurement of turbine speed.
Jumper blocks for signal flapping: The jumper blocks play a key role in enabling a set of three-speed inputs to flap to all three PPRO I/O packets, optimizing signal distribution for uniform functionality.
125 V DC TMR Voting Output contacts: These output contacts, labeled H2A and H4A, are key components for system trip activation, ensuring fail-safe measures in the event of an emergency.
Voltage Detection circuits: Four circuits from 24 to 125 V DC are dedicated to monitoring trip strings to improve system safety and reliability by continuously monitoring voltage levels.
Sub-board connectors: The IS200TREAH2ACC includes sub-board connectors that allow for optional feature extensions, providing scalability and customization possibilities for additional or enhanced features.
TMR system signal distribution
In Triple modular redundancy (TMR) systems, signal distribution is facilitated through JX1, JY1 and JZ1 DC-62 PPRO connectors, ensuring redundancy and consistent function of multiple components, thereby enhancing system reliability and safety
Install
Wiring Configuration: IS200TREAH2ACC Voltage Detection and Circuit Breaker Relay wiring: The voltage detection circuit and the necessary circuit breaker relay connections are carefully connected to the I/O terminal designated TB1. This setting helps to reliably and efficiently handle voltage monitoring and system trip activation.
Passive pulse rate pickers: The passive pulse rate pickers are connected to the TB2 and play a key role in sensing the toothed wheels and accurately measuring turbine speed.
Terminals and specifications: I/O terminals: Each terminal (TB1 and TB2) is securely secured using two screws to ensure stability and a stable connection. These modules are designed with 24 terminals and are capable of accepting wires up to #12 AWG for robust and efficient wire connections.
Shielded end strips: The shielded end strips are adjacent to each terminal and securely connected to the grounding of the chassis, providing an additional layer of protection against potential interference and ensuring signal integrity and system reliability.
This careful wiring configuration, the connection of specific components to specified terminals, and the shielded end strips ensure the safe and orderly installation of the patch boards. This careful installation procedure is essential for optimal function and performance within the turbine system.
